FESTO Vacuum nozzle VN-10-H-T4-PQ2-VQ2-O2-P 536805 30 V DC QS-6, Muffler Nominal width (details) 0.95 mm Enclosure mater
EAN:
Part number:
Item no:
Highlights & Details
FESTO Vacuum nozzle VN-10-H-T4-PQ2-VQ2-O2-P 536805 30 V DC QS-6, Muffler Nominal width (details) 0.95 mm Enclosure mater
Technical specifications
- Display type: LED
- Switch-off time<: = 4 ms
- Type of silencer: Open
- Mounting type: With through hole
- Operating pressure: 1 ... 8 bar
- Operating pressure for max. suction volume flow: 3 bar
- Operating pressure for max. vacuum: 3.5 bar
- Operating medium: Compressed air according to ISO 8573-1:2010 [7:4:4]
- Operating voltage range DC: 15 ... 30 V
- CE mark (see declaration of conformity): According to EU EMC directive
- Pressure measuring range: -1 ... 0 bar
- All mounting positions permitted
- Switch-on time<: = 4 ms
- Setting range threshold values: -1 ... 0 bar
- Setting options: Teach-in
- Ejector characteristic: High vacuum
- Standard
- Electrical connection: M8
- 3-pins
- Accuracy FS: 1.5%FS
- Note on operating and control medium: Oiled operation not possible
- Inductive protective circuit: Adapted to MZ, MY, ME coils
- Integrated function: Muffler open
- Vacuum switch
- KC-MARK: KC-EMC
- Constructive structure: T-shape
- Corrosion resistance class KBK: 1 - low corrosion stress
- Short-circuit resistance: Isochronous
- Long-term drift: ±0.5% FS max.
- Max. Tightening torque: 0.6 Nm
- Max. output current 100 mA
- Max. Suction volume flow against atmosphere: 21.8 l/min.
- Max. Vacuum: 0.93
- Medium temperature: 0 ... 60 °C
- Measured variable: Relative pressure
- Measuring principle: Piezoresistive
- Measurement method: Relative
- Nominal operating pressure 6 bar
- Nominal diameter of lava nozzle: 0.95 mm
- Pneumatic connection 1: QS-6
- Pneumatic connection 3: Muffler open
- Product weight: 36 g
- Pitch: 16 mm
- Cleaning recommendation: Soapy water
- Residual current< = 0.3 mA
- Residual ripple: 0.1
- Sound pressure level at rated operating pressure 70 dB(A)
- PNP switch output
- Switching element function: Closer
- Switching function: Threshold comparator
- Threshold value with variable hysteresis
- Switching status indicator: LED
- Protection class: IP40
- Voltage drop< = 1.5 V.
- Temperature coefficient Switching point 0.05 %/K.
- Overload resistance: Available
- Ambient temperature: 0 ... 50 °C
- Vacuum connection: QS-6
- Reverse polarity protection: For all electrical connections
- Material seals: NBR
- Material: POM
- Material casing: POM-reinforced
- Fiber optic cable material: PC
- Material Muffler: PE
- Connector housing material: Brass
- PA
- chrome-plated and nickel-plated
- Material jet nozzle: Aluminum wrought alloy
- Keypad material: POM
- Screw connection material: Brass
- Nickel-plated
- Approval: RCM Mark
- Operating medium
Compressed Air
- Operating temperature
- Type
Corrosion resistance class KBK: 1 - low corrosion stress
- Manufacturer part #
536805
IP40
- Enclosure material
POM
- Connection
QS-6
Muffler
- Medium
Compressed air
- Sealant
NBR
- Component function
Maker
- Control pressure (max.)
-1 bar
- Max. operating pressure
8 bar
- Operating pressure (min.)
1 bar
- Operating voltage
30 V DC
- Min. operating voltage
15 V DC
- Nominal width
0.95 mm
- Max. operating voltage
30 V DC
- Media temperature (range)
- Max. ambient temperature
+50 °C
- Min. ambient temperature
0 °C
- Weight
36 g
- Product type
Vacuum nozzle
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2204310 FESTO Vacuum nozzle VN-10-H-T4-PQ2-VQ2-O2-P 536805 30 V DC QS-6, Muffler Nominal width (details) 0.95 mm Enclosure mater
Description
Hints
The kv factor indicates the volume flow through a valve, measured in litres/min at 1 bar and at a water temperature between 5 and 30°C. The QNn factor indicates the gas volume flow, measured in litres/min
