Benning CM 2-1 Clamp meter, Handheld multimeter Digital LoZ CAT IV 300 V, CAT III 600 V Display (counts): 4000
EAN:
Part number:
Item no:
56 Piece(s)
Do your needs go beyond this?
Sales and shipping:
Number
Total (€ 239.50 / piece)
€
Highlights & Details
True RMS-Digital clip-on ammeter multimeter Benning CM 2-1
- Multifunctional measuring device for many applications in electrical installation and electrical industry
- Ideal for measuring smaller currents
- Current, voltage and resistance measurement
- Auto-V-function with low input impedance
- Continuity and diode test
- Frequency and capacitance reading
- Low pass filter, Volt sensor
- CAT IV 300 V, CAT III 600 V
Technical specifications
- Voltage reading range DC (min.)
100 µV
- Product type
Clamp meter
- Voltage DC reading range (max.)
600 V
- V AC reading range (min.)
100 µV
- V AC reading range (max.)
600 V
- Amperage reading range DC (min.)
10 mA
- A DC reading range (max.)
400 A
- A AC reading range (min.)
10 mA
- Amperage reading range AC (max.)
400 A
- Reading range - resistance
-
- Reading range - capacity
-
- Frequency reading range
-
- Temperature
-
- Basic accuracy
1.5 %
- Frequency range
0.01 Hz - 50 K Hz
- Power supply (details)
2x AAA battery
- Height
110.0000 mm
- Width
220.0000 mm
- Weight
0.4800 kg
Manufacturer's standards (no certificate)
- Reading category
CAT IV 300 V
CAT III 600 V
- Voltage metering
AC/DC
- Current reading
AC/DC
- Type
CM 2-1
- Display
Digital
- Display (counts)
4000
- Dim
(W x H) 220.0000 mm x 110.0000 mm
- Features
LoZ
- Factory colour
Multicolour
- Displays
2000 Counts, LCD
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2446082 Benning CM 2-1 Clamp meter, Handheld multimeter Digital LoZ CAT IV 300 V, CAT III 600 V Display (counts): 4000
Description
Multifunctional measuring device for many applications in electrical installation and electrical industry. Measure high currents safely and without contact. Precise, true RMS measurement method. Ideal for measuring small currents (automotive, photovoltaic, industrial). Current, voltage, resistance, frequency and capacity measurement. Continuity and diode test. Auto-V-function with low input impedance (LoZ). Low-pass filter (HFR) for measurements on clocked motor drives. Volt sensor (NCV) for non-contact detection of phase voltage (LCD)
This text is machine translated.
This text is machine translated.
Features
- True RMS digital clamp-on ammeter multimeter
- 4-digit illuminated LCD display (4000 points) with light sensor
- ideal for measuring smaller currents
- Current 10 mA - 400 A AC/DC
- Voltage 0.1 mV - 600 V AC/DC
- True RMS
- Resistance 0.1 Ohm - 40 MOhm
- Frequency 1 Hz - 50 kHz
- Capacity 0.001 µF - 10000 µF
- . Continuity testing
- Diode test
- AutoV function with low input impedance (LoZ) to suppress “blind voltages”. Low pass filter (HFR high frequency suppression, 800 Hz) for measurements on clocked motor drives
- Voltssensor (NCV) for non-contact phase and cable break testing (buzzer/LCD)
- Automatic measuring range selection
- Shutdown
- Low battery indicator
- HOLD, MAX./MIN.
- Pliers opening 27 mm CAT IV 300 V CAT III 600 V
- This text is machine translated.
Scope of delivery
- Incl. Bag, 2 x 1.5 V Micro/ AAA/ LR03 battery, test leads.
