HARTING 09330242616 Pin inset Han® E 24 + PE Spring-loaded 1 pc(s)
EAN:
Part number:
Item no:
Product type
Pin inset
Series
Han® E
Type
Han 24ES-STi-S
Manufacturer part #
09330242616
Features
copper-plated
tin-plated contacts
Number
Total (€ 50.41 / piece)
€ 50.41
plus VAT.
Highlights & Details
HARTING 09330242616 Pin inset Han® E 24 + PE Spring-loaded 1 pc(s)
Our service for you
Technical specifications
- Type
Han 24ES-STi-S
- Product type
Pin inset
- Series
Han® E
- Manufacturer part #
09330242616
- Features
copper-plated
tin-plated contacts
- Factory colour
Grey
- Total no. of pins
24 + PE
- Size
24 B
- Connection
Spring-loaded
- Mating cycles
≥ 500
- Series
1 - 24
- Rated voltage
500 V
- Test current
16 A
- Content
1 pc(s)
- Core connector
0.14 - 4 mm²
- Number of pins
24
- Max. temperature
+125 °C
- Min. temperature
-40 °C
- Temperature range
-40 - +125 °C
- Contamination level
3
- Leading contact (PE)
Yes
- Core cross section (max.)
4 mm²
- Core cross section (min.)
0.14 mm²
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 740981 HARTING 09330242616 Pin inset Han® E 24 + PE Spring-loaded 1 pc(s)
Description
Heavy industrial connectors for the toughest requirements in automotive, machine and plant engineering.
