LAPP 2170831/1 Bus cable UNITRONIC® BUS 2 x 1.5 mm² Black Sold per metre
EAN:
Part number:
Item no:
Product type
Bus cable
Cable type
UNITRONIC® BUS
No. of leads
2 x
Cross section (each core)
1.5 mm²
Cross section
2 x 1.5 mm²
Datasheet (PDF)
Quantity (meter)
Savings
Package size (plus VAT.)
1
-
€ 4.61
5
7% = € 0.30
€ 4.31
10
9% = € 0.42
€ 4.19
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.61 / piece)
€ 4.61
plus VAT.
Highlights & Details
UNITRONIC Bus cables AS-i ( AS-INTERFACE)
- LAPP CABLE is a member of the AS International Association user organisation.
Technical specifications
- Product type
Bus cable
- Cable type
UNITRONIC® BUS
- No. of leads
2 x
- Cross section (each core)
1.5 mm²
- Cross section
2 x 1.5 mm²
- Cable features
Flame-retardant
Oil-resistant
Suitable for drag chains
- Width
10 mm
- Height
4 mm
- Type
Transmission power supply 30 V/DC
- Factory colour
Black
- Content
Sold per metre
- Test voltage
Wire/Wire: 2000 V
- Packaged
No
- Sold per metre
Yes
- Halogen-free
No
- Shielded
No
- Manufacturer part #
2170831/1
- Insulation material
TPE (low-odour thermoplastic elastomer )
- Min. temperature range (fixed installation)
-40 °C
- Max. temperature range (fixed installation)
+105 °C
- Min. temperature range (flexible installation)
-30 °C
- Max. temperature range (flexible installation)
+105 °C
- Certification marks
UL/CSA-Versions: UL- (USA) und CSA- (Canada)
- Type
Unitronic bus ASI (TPE) BK UL/CSA (AWM)
- Max. length sold by the metre
500 m
- Insulation
TPE
- Cable type
Bus ASI (TPE )BK UL/CSA (AWM)
- Type
UNITRONIC® Bus ASI (TPE )BK UL/CSA (AWM)
Documents & Downloads
Datasheet
Datasheet 602277 LAPP 2170831/1 Bus cable UNITRONIC® BUS 2 x 1.5 mm² Black Sold per metre
User & Safety Instructions
User & Safety Instructions 602277 LAPP 2170831/1 Bus cable UNITRONIC® BUS 2 x 1.5 mm² Black Sold per metre
Information
Information 602277 LAPP 2170831/1 Bus cable UNITRONIC® BUS 2 x 1.5 mm² Black Sold per metre
Description
Networking system for the lowest level field area (binary sensors and actuators). Data and power are transmitted between the control unit and peripherals via an unshielded, geometrically coded, two-conductor flat cable (protection against incorrect polarity). Insulation displacement technology is used to connect the conductors in the ASI modules. The Europe-wide EN 50295 and international IEC 62026-2 standards apply to ASI.
"AS-INTERFACE = Developed as a cost effective alternative to factory automation at the lowest level (sensor / actuator level). Commonly used in combination with PROFIBUS, INTERBUS, CAN and DEVICENet.
ASI = Actuator Sensor Interface. LAPP CABLE is a member of the AS International Association user organisation."
"AS-INTERFACE = Developed as a cost effective alternative to factory automation at the lowest level (sensor / actuator level). Commonly used in combination with PROFIBUS, INTERBUS, CAN and DEVICENet.
ASI = Actuator Sensor Interface. LAPP CABLE is a member of the AS International Association user organisation."
