Buy Navilock NL-8012U GPS receiver Black 1 pc(s)

A black card reader with a USB port, commonly used for smart cards or security cards, is resting on a light-coloured surface.

Datasheet (PDF)

Fast track dispatch on Wed, 5 Aug

22 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 113.44 / piece)

€ 113.44

plus VAT.

Report legal concerns

Highlights & Details

Navilock NL-8012U

U-blox 8 UBX-M 8030-KT chipset
Processes signals from up to 72 satellites simultaneously
IPX6 protection class

Technical specifications

Product type: GPS receiver

Interfaces: USB

GPS features: Splashproof casing

Power supply: USB (built-in)

Factory colour: Black

Height: 22 mm

Width: 45 mm

Depth: 65 mm

Weight: 0.223

Dim: (W x H x D) 45 x 22 x 65 mm

Cable design: Round

Version: Cable

Keyboard layout: English, QWERTY

Cable use: C13/C14 appliances

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 1409240 Navilock NL-8012U GPS receiver Black 1 pc(s)

User & Safety Instructions

User & Safety Instructions 1409240 Navilock NL-8012U GPS receiver Black 1 pc(s)

Description

The USB 2.0 multi-GNSS receiver with the u-blox 8 chipset has a built-in active antenna. Navigation can be performed in connection with a notebook and suitable navigation software.

This text is machine translated.

Features

Connection: USB 2.0 type A plug
Chipset: u-blox 8 UBX-M 8030-KT
Frequency: GPS L1, L1, 1602,5625 1575,4200 MHz; GLONASS-1615,5000 MHz; BEIDOU COMPASS: B1, 1561,0980 MHz; GALILEO: E1, 1575,4200 MHz; QZSS: L1, 1575,4200 MHz
Processes signals from up to 72 satellites simultaneously
Supports AssistNow online/offline, SBAS (WAAS, EGNOS, and MSAS) QZSS
Supports NMEA 0183 protocols: GGA, GSA, GSV, RMC, VTG
Auto Baud rate up to 115200 bps
Update rate: 18 Hz (for example: simply GNSS GPS solo); multiple GNSS: 10 Hz (e.g. GPS and GLONASS)
Max. sensitivity 167 dBm
IPX6 protection class
Magnetic, non-slip bottom panel
LED display for GPS status
Operating temperature: -20 °C ~ 60 °C
Voltage supply: 5 V DC
Power consumption: max. 45 mA
Cold start in approx. 26 seconds
Hot start in about 1 second
Positional accuracy: 2.5 m CEP (circular error probable) and 2 m CEP with SBAS
Cable length approx. 4.5 m
Microsoft Sensor and location platform
Compatible with Windows application software (e.g. weather, cards, etc.)
GNSS positioning platforms via API (32-bit).
