NETGEAR GS105E-200PES GS105E Network switch 5 ports 1 GBit/s
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 26.04 / piece)
€ 26.04
plus VAT.
Highlights & Details
Netgear ProSafe™ GS105E 5 port Gigabit Ethernet switch
- T-Entertain suitable (multicast)
- Port mirroring
- Bandwidth managemet for avoiding data jams
Technical specifications
- Product type
Network switch
- Transfer rate
1 GBit/s
- 10/100/1000 Mbps ports
5 x
- Auto-uplink at each port
Yes
- MAC addresses
4000
- Weight
300 g
- Width
94 mm
- Height
104 mm
- Depth
28 mm
- Type
GS105E
- Interfaces
RJ45
- Factory colour
Multicolour
- Port
5 ports
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 973846 NETGEAR GS105E-200PES GS105E Network switch 5 ports 1 GBit/s
User & Safety Instructions
User & Safety Instructions 973846 NETGEAR GS105E-200PES GS105E Network switch 5 ports 1 GBit/s
Warranty Terms
Warranty Terms 973846 NETGEAR GS105E-200PES GS105E Network switch 5 ports 1 GBit/s
Description
The ProSafe Plus switches optimise the traffic in your network by enabling port as well as tag-based prioritisation. In this way the traffic that cannot wait gets preference over the less critical traffic packets. The switch masters the so-called IGMP v3 snooping. This function is necessary for distributing the IPTV data (multicast) via this switch in such a way that there are no disturbing hangers at the TV-set, in case other network devices generate traffic at the same time.
The VLAN-technology of the switches enhances the security and enables managing the domain collisions.
The ProSafe Plus switches offer you an excellent cost-benefit ratio and enable a network management at a professional level.
The VLAN-technology of the switches enhances the security and enables managing the domain collisions.
The ProSafe Plus switches offer you an excellent cost-benefit ratio and enable a network management at a professional level.
Features
- D-Link Green-Technology integrated
- Switching power 16 Gbit/s
- Automatic MDI/MDIX-detection on all ports
- Secure section determination (store-.and-forward method)
- Full/half-duplex for Ethernet/fastEthernet speed
- IEEE 802.3x flow control
- Support of Jumbo frames with 9,216 bytes
- RoHS compliant
- Plug-and-Play installation
- IEEE 802.3 10BASE-TEthernet (twisted-pair copper cable)
- IEEE 802.3u 100BASE-TX Fast Ethernet(twisted-pair copper cable)
- IEEE 802.3ab 1000BASE-TGigabit .Ethernet (twisted-pair copper cable)
- ANSI/IEEE 802.3 automatic N-way-.speed determination
- IEEE 802.3x flow control
- IEEE 802.3az energy-efficient Ethernet .(EEE)
- Ethernet: 10 MBit/s (half-duplex);20 Mbit/s (full-duplex)
- Fast Ethernet: 100 MBit/s (half-duplex); 200 Mbit/s (full-duplex)
- Gigabit Ethernet: 2000 MBit/s (full-duplex)
- Media interface: Automatic detection at all ports
- LED-displays: For each port: Connection/Activity/Speed; Each device: Power
- Transmission method: Store-and-forward
- MAC-address table: 8,000 entries per device.
- Address adoption: Automatic update
- Packet filtering/forwarding rate: Ethernet: 14,880 packets for each port
- Fast Ethernet: 148,800 packets for each port
- Gigabit Ethernet: 1,488,000 packets for each port
- RAM-buffer: 128 Kb per device.
- Voltage values: Switching power supply with 5 V/1 A (Energy Star .Level V)
- Power consumption: Ready state (standby): AC-input power: 2.2 W maximum: AC-input power: 4.8 W
Scope of delivery
- ProSafe 5 Gigabit ethernet switch
- Wall mounting set
- 12V, 1.0A power supply
- Installation-CD with configuration utility software
- Quick installation guide
