Phoenix Contact CRIMPFOX-M SC 1/DIE 1212083 Crimp die Non-insulated blade terminal receptacles 0.1 up to 1 mm² Suitable
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 73.94 / piece)
€ 73.94
plus VAT.
Only 1 Piece(s) available
Technical specifications
- Compression: B-Crimp; capacity 0.1 - 0.25 / 0.25 - 0.5 / 0.5 - 1 mm²; AWG 26 - 24/ 24 - 22 / 22-18; Number of cavities: 3
- Product type
Crimp die
- Manufacturer part #
1212083
- Range of uses
Non-insulated blade terminal receptacles
- Crimp area AWG
18 up to 26 awg
- Crimp area (min.)
0.1 mm²
- Crimp area (max.)
1 mm²
- Crimp area AWG (min.)
26 awg
- Crimp area AWG (max.)
18 awg
- Length
114 mm
- Width
75 mm
- Height
25.5 mm
- Weight
72 g
- Suitable for
Phoenix Contact
- Suited for model
469547
- Crimp area
0.1 up to 1 mm²
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 469368 Phoenix Contact CRIMPFOX-M SC 1/DIE 1212083 Crimp die Non-insulated blade terminal receptacles 0.1 up to 1 mm² Suitable
User & Safety Instructions
User & Safety Instructions 469368 Phoenix Contact CRIMPFOX-M SC 1/DIE 1212083 Crimp die Non-insulated blade terminal receptacles 0.1 up to 1 mm² Suitable
Description
Die for Crimpfox-M, for non-insulated female spade connectors 0.1 - 1 mm², packed in a mounting storage box
