Self Electronics SLT80-700IL-EU LED driver Constant current 80 W 325 - 700 mA 60 - 246 V DC adjustable, Surge protection
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 21.84
3
4% = € 0.95
€ 20.89
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 21.84 / piece)
€ 21.84
plus VAT.
Highlights & Details
SLT80-700IL-EU
- Constant current
- 60 - 246 V DC
- 325 - 700 mA
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 280 x 30 x 22 mm
- Factory colour
Grey
- Output voltage (max.)
246 V DC
- Output voltage (min.)
60 V DC
- Max. output current
700 mA
- Output current (max.) - rounded
700 mA
- Operating voltage
230 V AC
- LED driver features
adjustable
Surge protection
Overvoltage
not dimmable
IP20
- Connection
Push-in connector
- Max. power
80 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
325 mA
- Input voltage (max.)
264 V AC
- Min. input voltage
198 V AC
- Weight
230 g
- Power (min.)
34 W
- Power range
34 up to 80 W
- Type
Pulsed
- Width
30 mm
- Height
22 mm
- Length
280 mm
- Max. temperature
+50 °C
- Min. temperature
-20 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1947713 Self Electronics SLT80-700IL-EU LED driver Constant current 80 W 325 - 700 mA 60 - 246 V DC adjustable, Surge protection
User & Safety Instructions
User & Safety Instructions 1947713 Self Electronics SLT80-700IL-EU LED driver Constant current 80 W 325 - 700 mA 60 - 246 V DC adjustable, Surge protection
Warranty Terms
Warranty Terms 1947713 Self Electronics SLT80-700IL-EU LED driver Constant current 80 W 325 - 700 mA 60 - 246 V DC adjustable, Surge protection
Description
Features
- Independant operating device
- Non-insulated design
- Flicker-free design
- Constant current
- IP20
- Protected against overload, short-circuit and temperature protection
- EN61347-1, EN61347-2-13, EN55015, EN61000-3-2 etc.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
