Siemens 3VA9123-0RL30 Current differential protection 1 pc(s) Adjustment range (amperage): 0.03 - 30 A Switching voltage
EAN:
Part number:
Item no:
Product type
Current differential protection
Amperage adjustment range (max.)
30 A
Connection
Terminal strip
Type
3VA9123-0RL30
Amperage adjustment range (min.)
0.03 A
Datasheet (PDF)
Number
Total (€ 987.39 / piece)
€ 987.39
plus VAT.
14-day return policy included
Highlights & Details
TERMINAL COVER PLUG-IN, DRAW-OUT OFFSET
Our service for you
Technical specifications
- Product type
Current differential protection
- Type
3VA9123-0RL30
- Amperage adjustment range (min.)
0.03 A
- Amperage adjustment range (max.)
30 A
- Adjustment range (amperage)
0.03 - 30 A
- No. of pins
3-pin
- Switching voltage (max.)
690 V AC
- Compatible with series
Siemens 3VA series
- Compatible with
Siemens
- Mounting type
Screw-fit
- Min. temperature
-25 °C
- Max. temperature
+70 °C
- OCR type
ETU820
- Connection
Terminal strip
IP40
- Depth
86 mm
- Width
105 mm
- Height
115 mm
- Dim
(W x H x D) 105 x 115 x 86 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
Other
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 1727583 Siemens 3VA9123-0RL30 Current differential protection 1 pc(s) Adjustment range (amperage): 0.03 - 30 A Switching voltage
User & Safety Instructions
User & Safety Instructions 1727583 Siemens 3VA9123-0RL30 Current differential protection 1 pc(s) Adjustment range (amperage): 0.03 - 30 A Switching voltage
Description
terminal cover offset for plug-in and draw-out sockets accessory for: circuit breaker, 4 pole 3VA1 100/160 Connection technology for 3VA molded-case circuit breakers The connection technology of the 3VA molded case circuit breakers is designed to support uncomplicated and convenient commissioning of the 3VA molded case circuit breakers and to meet all installation requirements. www.siemens.de/3VA. Siemens offers a comprehensive portfolio of protection, switching, measuring and monitoring devices, distribution systems as well as switches and sockets for safe and efficient electrical infrastructure in buildings and industry.
