Siemens 5SV33446 5SV3344-6 RCCB A 4-pin 40 A 0.03 A 400 V
EAN:
Part number:
Item no:
Product type
RCCB
Number of pins
4
Release characteristics
A
Differential current rating
0.03 A
Nominal current - rounded value
40 A
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 28.56
3
4% = € 1.11
€ 27.45
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 28.56 / piece)
€ 28.56
plus VAT.
Highlights & Details
GROUND fault circuit type A 40A 3+N-pole 30mA 400V 4TE
- Type A 40 A.
- 3+N-pin
- Breaking current 30 mA.
- 400 V 4TE
- IP20, for distributor installation, with connected conductors
Technical specifications
- Mechanical life (Cycles): 10000
- IP20, for distributor installation, with the connected conductors
- Product type
RCCB
- Number of pins
4
- Release characteristics
A
- Differential current rating
0.03 A
- Nominal current
40 A
- Nominal current - rounded value
40 A
- Dim
(L x W x H) 70 x 72 x 90 mm
- Type
Design of the product: without delay; Mounting Type: DIN rail
- Switch-off capacity
0.8 kA
- Factory colour
Grey
- Content
1 pc(s)
- Nominal voltage
400 V
- Width
72 mm
- Height
90 mm
- Length
70 mm
- Depth
70 mm
- Weight
0
AC
70 mm
40 A
400 V
4
0.03 A
4
FALSE
0.75-35 mm²
0.75-35 mm²
-25-45 °C
TRUE
- UKCA
no
Documents & Downloads
Datasheet
Datasheet 1419134 Siemens 5SV33446 5SV3344-6 RCCB A 4-pin 40 A 0.03 A 400 V
User & Safety Instructions
User & Safety Instructions 1419134 Siemens 5SV33446 5SV3344-6 RCCB A 4-pin 40 A 0.03 A 400 V
Description
Residual-current circuit breaker, 4-pole, type A, in: 40 A, 30 mA, Un AC: 400 V FI-circuit breaker SENTRON 5SV3 for the comprehensive protection of persons and property against electrical shock.
The FI-circuit breaker offers reliable safety in the installation by the usual comprehensive and protection against contact. You can release the FI circuit-breaker without tools from the DIN rail or from the bus rail system with the convenient slide-hand operation. The data matrix code on the device gives you quick access to all technical data in the Siemens Industry Online Support APP.
The SENTRON protection relays can be extended by many functions using the integrated accessories from the system module.
Optimal technology for your safety - only from Siemens.
