Buy SpeaKa Professional TV/receiver, Audio/phono Extractor SP-HDA-510 [HDMI - HDMI] 3840 x 2160 Pixel eARC, S/PDIF + analogu

Black HDMI switcher with 'Speaker Professional' and 'Select' labels, three HDMI inputs, optical and audio output.

Back of an electronic device with connections: Audio, DC 5V, Optical, eARC, HDMI/ARC, IN-3, IN-2. Audio output and optical input visible.

A black media streaming box with HDMI port, power adapter, HDMI cable, remote control and AV cable. Suitable for home cinema setups.

A living room with modern furnishings. A television mounted on the wall displays a streaming service menu. Someone is holding a remote control.

'Diagram shows PS5 console on the left, connected to an HDMI splitter in the centre, which feeds a television at the top right and a sound system at the bottom right.'

1/7

Our service for you

Fast track dispatch on Wed, 23 Sep

143 Piece(s) (Only while stocks last)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 52.09 / piece)

€ 52.09

plus VAT.

14-day return policy included

Report legal concerns

Highlights & Details

Speaka Professional SP-HDA-510 HDMI eARC audio extractor with 3-port HDMI switch

One HDMI ouput for TV 4K@60/HDR video and audio signals and one for eARC soundbar
3 HDMI inputs for different HDMI devices such as gaming consoles and streaming boxes
TV signal can be transmitted back to soundbar via eARC to play high-quality surround sound
Build-in eARC automatically detects the source of the signal (TV or external signal)
Supports Dolby Atmos, DTS HD, Dolby TrueHD
Supports S/PDIF, stereo 3.5 mm audio output
Supports CEC (Consumer Electronics Control)
HDCP 2.3

Technical specifications

Product type: TV/receiver

Connection type: HDMI

No. of A connectors: 3 x

Type A: HDMI socket

Type B: HDMI socket
Toslink socket (ODT)
Jack socket 3.5 mm

Video resolution: 3840 x 2160 Pixel

Factory colour: Black

Connector version: straight

Cable features: eARC
S/PDIF + analogue output
built-in 3-port HDMI switch

Version: Extractor

Cable use: TV/receiver
Audio/phono

Weight: 156.33 g

Length: 175 mm

Width: 86.6 mm

Height: 26.3 mm

Dim: (L x W x H) 175 x 86.6 x 26.3 mm

Range of use: Household

Port: 3+2 ports

Supported audio file formats: Dolby-AC3
DTS
LPCM 2.0
LPCM 5.1
LPCM 7.1

Plastic free packaging: Plastic-free packaging

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2525735 SpeaKa Professional TV/receiver, Audio/phono Extractor SP-HDA-510 [HDMI - HDMI] 3840 x 2160 Pixel eARC, S/PDIF + analogu

Description

The SP-HDA-510 is a video and audio converter with three HDMI inputs that can be switched by button or remote control and two HDMI outputs, one for TV 4K@60/HDR video-audio and video signals, one for the earc soundbar as well as S/PDIF and analogue stereo output.

This text is machine translated.

Scope of delivery

HDMI eARC audio extractor with 3-port HDMI switch
USB power adapter
3.5 mm to RL cable
Remote control
User manual
