Buy VOLTCRAFT AM-60X46/30V/1,5A/DC AM-60X46/30V/1,5A/DC Panel-mounted measuring device AT THE-60 X 46/30 V/1.5 A/DC 30 V/1.5

Analogue measuring device displays voltage and current on a scale. Scale ranges from 0 to 30 volts/amperes, with the needle pointing to approximately 1.2.

Analogue ammeter with scale from 0 to 3 amperes and 0 to 30 volts. Pointer indicating 1.5 amperes. Instrument for DC measurement.

1/2

Our service for you

Fast track dispatch on Mon, 14 Sep

106 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 15.12 / piece)

€ 15.12

plus VAT.

Report legal concerns

Highlights & Details

Panel-mounted measuring device AT THE-60 X 46/30 V/1.5 A/DC

60 x 46 mm
0 - 30 V/0 - 1.5 A/DC
Double scale

Technical specifications

Product type: Analogue rack-mount meter

Reading type: DC voltage
DC current

Reading range (min.): 0 V
0 A

Reading range (max.): 30 V
1.5 A

Dim: (W x H) 60 mm x 46 mm

Instrument type: Moving coil

Temperature range: -25 - +55 °C

Type: AM-60X46/30V/1,5A/DC

Recess diameter: 38 mm

Features: Dual reading dial

Recess depth: 22.3 mm

Electrical connection: Screw terminals

Weight: 44 g

Factory colour: White
Black

Content: 1 pc(s)

Width: 60 mm

Height: 46 mm

: Manufacturer's standards (no certificate)

Accuracy class: 2.5

Reading range: 30 V/1.5 A

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 103082 VOLTCRAFT AM-60X46/30V/1,5A/DC AM-60X46/30V/1,5A/DC Panel-mounted measuring device AT THE-60 X 46/30 V/1.5 A/DC 30 V/1.5

Warranty Terms

Warranty Terms 103082 VOLTCRAFT AM-60X46/30V/1,5A/DC AM-60X46/30V/1,5A/DC Panel-mounted measuring device AT THE-60 X 46/30 V/1.5 A/DC 30 V/1.5

Description

This text is machine translated.

Analogue panel-mounted moving coil meter for display of DC voltages or DC currents. The pointer instrument enables the classic analogue display, the fluctuating values as linear pointer can be seen. The dual display enables the display of 2 parameters with a measuring device by switching the input circuitry. Ideal for building your own power supplies for the display of voltage and current.
