Buy Wachendorff PID Temperature controller K, S, R, J, Pt100, Pt500, Pt1000, Ni100, PTC1K, NTC10K SSR, 5 A relay, 5 A relay

Digital display instrument shows '168.9' in red at the top and '185.1' at the bottom. Two blue function buttons on the right.

Product type

Temperature controller

Thermostat type

PID

Operating voltage

12 V DC

230 V

Outputs (thermostats)

SSR

5 A relay

No. of relay outputs

Datasheet (PDF)

Fast track dispatch on Mon, 14 Sep

4 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 151.25 / piece)

€ 151.25

plus VAT.

Only 4 Piece(s) available

Report legal concerns

Highlights & Details

Wachendorff UR3274U5 PID Temperature Controller K, S, R, J, Pt100, PT500, Pt1000, Ni100, PTC1K, NTC10K relay 5 A, relay 8 A, RS485

PID controller in 32 x 74 mm format; simple programming via keyboard, PC software or
Wachendorff EMG APP;Universal power supply;Universal input for process signals, thermocouples, Pt100,
PT500, Pt1000 and potentiometer;2-line LED display;two switching outputs as relay and one relay/SSR driver;RS485 interface

Technical specifications

SSR output: 12 V/DC at max. 30 mA
Power supply 24 to 230 V/AC/DC

Product type: Temperature controller

Type: UR32742A

Thermostat type: PID

Operating voltage: 12 V DC
230 V

Outputs (thermostats): SSR
5 A relay
5 A relay

No. of relay outputs: 2

No. of transistor outputs: 1

Dim: (L x W x H) 53 x 77 x 35 mm

Height: 35 mm

Length: 53 mm

Width: 77 mm

: IP65 (on front)/IP20 (on back)

Sensor type: K
S
R
J
Pt100
Pt500
Pt1000
Ni100
PTC1K
NTC10K

Manufacturer part #: UR32742A

Mounting type: Recess-mount

Digital inputs: 1 x digitally programmable

Assembly dimensions: 32 x 74 mm

Interfaces: RS485 Modbus RTU

Sensor type: Thermocouple type K, S, R, J, Pt100, PT500, Pt1000, Ni100, PTC1K, NTC10K

Weight: 112 g

Documents & Downloads

Datasheet

Datasheet 2361683 Wachendorff PID Temperature controller K, S, R, J, Pt100, Pt500, Pt1000, Ni100, PTC1K, NTC10K SSR, 5 A relay, 5 A relay

Description

This small universal controller is a compact all-rounder. With a universal input for almost all standard temperature sensors, potentiometers as well as process signals, a universal supply and modern programming, operating and control technologies, this controller is the optimal solution for demanding applications. Freely configurable and with self-optimization it is best suitable for heating and/or cooling. 2-line display for setpoint and actual value as well as indicators for alarm outputs/function. Simple programming via 4 buttons or VIA app. High degree of protection IP65 from the front page.
