Image similar
Image similar
WAGO 2016-1304 Continuity 12 mm Pull spring Configuration: N Blue 1 pc(s)
EAN:
Part number:
Item no:
Product type
Continuity
Connection
Pull spring
Cross section (flexible) (max.)
24 mm²
Cross section (inflexible) (max.)
16 mm²
Nominal current - rounded value
76 A
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.61
5
7% = € 0.30
€ 4.31
10
9% = € 0.42
€ 4.19
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.61 / piece)
€ 4.61
plus VAT.
14 days return policy included
Highlights & Details
WAGO 2016-1304 Continuity 12 mm Pull spring Configuration: N Blue 1 pc(s)
- Wago 2016-1304, 12 mm, 91,8 mm, 36,9 mm, 800 V
- TOPJOB®S
- CAGE CLAMP®
Technical specifications
- Product type
Continuity
- Connection
Pull spring
- Configuration
N
- Cross section (flexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
24 mm²
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (inflexible) (max.)
16 mm²
- AWG (min.)
20
- AWG max.
4
- Clamp width
12 mm
- No. of rows
1
- Pins per row
3
- Number of pins
3
- Factory colour
Blue
- Nominal current
76 A
- Nominal current - rounded value
76 A
- Nominal voltage
800 V
- Min. stripping length
18 mm
- Stripping length (max.)
20 mm
- Manufacturer part #
2016-1304
- Content
1 pc(s)
- Type
Wago 2016-1304, 12 mm, 91,8 mm, 36,9 mm, 800 V
- Width
12 mm
- Weight
0.03
- Type
3-conductor
- Nominal current (details)
76 A
- Cross section
0.5 - 10/16 (rigid / flexible) mm²
- Connection
-
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 735305 WAGO 2016-1304 Continuity 12 mm Pull spring Configuration: N Blue 1 pc(s)
Datasheet 735305 WAGO 2016-1304 Continuity 12 mm Pull spring Configuration: N Blue 1 pc(s)
User & Safety Instructions
User & Safety Instructions 735305 WAGO 2016-1304 Continuity 12 mm Pull spring Configuration: N Blue 1 pc(s)
Description
The direct plug-Series 2016 protects against handling errors and allows simple plug of single-wire and stranded conductors.
