AFDD White 2-pin 40 A 230 V Siemens 5SM60242
EAN:
Part number:
Item no:
Product type
AFDD
Nominal voltage
230 V
Number of pins
2
Nominal current - rounded value
40 A
Factory colour
White
Datasheet (PDF)
Highlights & Details
AFDD, 1-40A 230V for LS and FI/LS switches 1+N 2TE Block
- 2 Division Units: 95 mm high, 54 mm wide, 68.5 mm deep
- Finger and hand protection against electric shock
- Mounting on DIN rail (REG)
Technical specifications
- Mounting type: DIN rail (REG)
- Over voltage category III
- Protection class: IP20
- Frequency: 50 Hz
- Contact protection against electrical shock: finger and hand back safely
- Net weight: 121 g
- Product type
AFDD
- Nominal voltage
230 V
- Factory colour
White
- Number of pins
2
- Dim
(W x H x D) 54 x 95 x 68.5 mm
- Nominal current
40 A
- Nominal current - rounded value
40 A
- Width
54 mm
- Height
95 mm
- Depth
68.5 mm
AC
70 mm
40 A
230 V
2
2
1
IP20
AC
Fire protection switch
Documents & Downloads
Datasheet
Datasheet 1726804 AFDD White 2-pin 40 A 230 V Siemens 5SM60242
User & Safety Instructions
User & Safety Instructions 1726804 AFDD White 2-pin 40 A 230 V Siemens 5SM60242
Description
AFDD, 1-40A 230V for LS and FI/LS switches 1+N 2TE Fire Protection Switch Block SENTRON 5SM6 for reliable and comprehensive protection of people, equipment and assets in the event of failure arcs Block.
Fire protection switches detect dangerous arcs at an early stage and switch them off safely before a fire occurs. With their innovative technology they cover the previously available protection gap of conventional devices reliably. The design as a Block enables the combination with many line circuit breakers or FI/LS-switches and thus reduces their storage position.
The fire protection blocks are available in versions up to 16 A and up to 40 A for 1- and 2-pole attachments.
The circuit breaker blocks can only be operated in conjunction with a circuit breaker or FI/LS switch.
Optimal technology for your safety - only from Siemens.
This text is machine translated.
Fire protection switches detect dangerous arcs at an early stage and switch them off safely before a fire occurs. With their innovative technology they cover the previously available protection gap of conventional devices reliably. The design as a Block enables the combination with many line circuit breakers or FI/LS-switches and thus reduces their storage position.
The fire protection blocks are available in versions up to 16 A and up to 40 A for 1- and 2-pole attachments.
The circuit breaker blocks can only be operated in conjunction with a circuit breaker or FI/LS switch.
Optimal technology for your safety - only from Siemens.
This text is machine translated.
Features
- Over voltage category III
- Operating temperature -25°C to + 45°C
