binder 09-9478-00-07 Bullet connector Socket, built-in Series (round connectors): 710 Total number of pins: 7 1 pc(s)
EAN:
Part number:
Item no:
Product type
Bullet connector
Connector type
Socket, built-in
Total no. of pins
7
Connection
Soldering
Content
1 pc(s)
Datasheet (PDF)
13 Piece(s)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 10.08
3
6% = € 0.58
€ 9.50
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 10.08 / piece)
€ 11.76
-14 %
€
Highlights & Details
Subminiature circular connectors series 710
- IP40
Technical specifications
- Type
09-9478-00-07
- Product type
Bullet connector
- Connector type
Socket, built-in
- Total no. of pins
7
- Connection
Soldering
- Content
1 pc(s)
- Max. temperature
+125 °C
- Nominal current
1 A
- Min. temperature
-55 °C
- Nominal current - rounded value
1 A
- Seal
bayonet
- Nominal voltage
125 V
- Contact material
Au (gold)
26
- Connection angle
180°
- Mounting hole diameter
M10 x 0.75
- Manufacturer part #
09-9478-00-07
- Cable Ø range
- Number of pins
7
- max. cross section
0.14 mm²
- Cross-section range
0.14 mm² (max)
- RoHS-compliant
IP40
- Series
710
- Type
Flange plug
- Nominal voltage (details)
125 V
- Nominal current (details)
1 A
- Contamination level
1
- Cross section
0.14 mm²
- Connection
Soldering
- Temperature range
- 40 - 85 °C
Documents & Downloads
Datasheet
Datasheet 738566 binder 09-9478-00-07 Bullet connector Socket, built-in Series (round connectors): 710 Total number of pins: 7 1 pc(s)
User & Safety Instructions
User & Safety Instructions 738566 binder 09-9478-00-07 Bullet connector Socket, built-in Series (round connectors): 710 Total number of pins: 7 1 pc(s)
Information
Information 738566 binder 09-9478-00-07 Bullet connector Socket, built-in Series (round connectors): 710 Total number of pins: 7 1 pc(s)
Description
· Connectors are used from the front to the panel section and screwed from behind
· Fixing with hexagon nut.
· Fixing with hexagon nut.
