binder 99-0217-70-07 Bullet connector Plug, straight Series (round connectors): 692 Total number of pins: 6 + PE 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 22.68
3
4% = € 0.98
€ 21.70
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 22.68 / piece)
€ 24.36
-7 %
€
Highlights & Details
Standard round connector series 692
- IP67
Technical specifications
- Connector type
Plug, straight
- Total no. of pins
6 + PE
- Connection
Screws
- Content
1 pc(s)
- Nominal current
10 A
- Nominal current - rounded value
10 A
- Seal
Screws
- Leading contact (PE)
Yes
- Nominal voltage
250 V
- Contact material
Ag (Silver)
- Cable Ø (max.)
8 mm
- Cable Ø up to
6 mm
- Cable Ø range
6 - 8 mm
- Cross-section range
1.5 mm² (max)
IP67
- Series
692
- Manufacturer part #
99-0217-70-07
- Type
Binder
- Type
Cable connector
- max. cross section
1.5 mm²
- Number of pins
6
- Nominal voltage (details)
4000 V
- Nominal current (details)
10 A
- Contamination level
3
- Connection angle
180°
- Cross section
0.34 - 1.5 mm²
22 - 16
- Pins
6 + PE
- Connection
Screw
- Temperature range
-40 - +100 °C
- Reading category
III
- RoHS-compliant
- Size
PG9
- Product type
Bullet connector
Documents & Downloads
Datasheet
Datasheet 733439 binder 99-0217-70-07 Bullet connector Plug, straight Series (round connectors): 692 Total number of pins: 6 + PE 1 pc(s)
User & Safety Instructions
User & Safety Instructions 733439 binder 99-0217-70-07 Bullet connector Plug, straight Series (round connectors): 692 Total number of pins: 6 + PE 1 pc(s)
Information
Information 733439 binder 99-0217-70-07 Bullet connector Plug, straight Series (round connectors): 692 Total number of pins: 6 + PE 1 pc(s)
Description
· Connector with screw lock
· Protection class IP67
· Available with screw and solder connection
· Protection class IP67
· Available with screw and solder connection
