BKL Electronic 0411030 0411030 SMB connector Plug, vertical mount 50 Ω 1 pc(s)
EAN:
Part number:
Item no:
Product type
SMB connector
Connector type
Plug, vertical mount
Impedance
50 Ω
Connection
Print
Content
1 pc(s)
Datasheet (PDF)
10 Piece(s)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.61
5
7% = € 0.30
€ 4.31
10
9% = € 0.42
€ 4.19
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.61 / piece)
€
Only 10 Piece(s) available
Highlights & Details
BKL Electronic 0411030 0411030 SMB connector Plug, vertical mount 50 Ω 1 pc(s)
- The plug socket - name, according to the shape of the inner conductor defined.
- This text is machine translated.
Technical specifications
- PCB mounting: 90°
- Soldered connection
- Product type
SMB connector
- Connector type
Plug, vertical mount
- Impedance
50 Ω
- Connection
Print
- Content
1 pc(s)
- Cable Ø
2.60 mm
- Max. frequency
4 GHz
- Case material
Brass gold plated
- Manufacturer part #
0411030
- Insulation resistance
500 MΩ
- Insulation material
PTFE
- Material (details)
Brass, gold plated
- RoHS-compliant
Yes
- Type
0411030
- Type
90° PCB mounting
- Frequency range
0 - 4 GHz
- Contact resistance
10 MΩ
- Connection
PCB
- Cable diameter (details)
2.6 mm
Documents & Downloads
Datasheet
Datasheet 730362 BKL Electronic 0411030 0411030 SMB connector Plug, vertical mount 50 Ω 1 pc(s)
User & Safety Instructions
User & Safety Instructions 730362 BKL Electronic 0411030 0411030 SMB connector Plug, vertical mount 50 Ω 1 pc(s)
Description
SMB stands for subminiature B and is used in frequency ranges up to 4 GHz. Unlike SMC plug connectors, this connector is only inserted and not screwed into place. It is used mainly for internal device connections.
