A circuit board with two grey plug terminal rows, with six soldered diodes in between. On the board it reads 'WAGO 8DB'.

A circuit board with two grey plug terminal rows, with six soldered diodes in between. On the board it reads 'WAGO 8DB'.

A series of vertical lines with numbers ranging from 2 to 16 at the top and bottom, with letters and numbers that could represent a code or sequence.

'Example of Morse code' arranged in rows; dots, dashes, and spaces represent letters and numbers.

1/3

WAGO

Datasheet (PDF)

Deutsch (Deutschland)

16 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 19.32 / piece)

€

Report legal concerns

Technical specifications

Content: 1 pc(s)

Dim: (W x H x D) 47 x 31.5 x 65.5 mm

Total no. of pins

Depth: 65.5 mm

Height: 31.5 mm

Width: 47 mm

Connection: Pull spring

Series: CAGE CLAMP® Serie 236

max. cross section: 2.5 mm²

Operating current: 1 A

Min. cross section: 0.08 mm²

RoHS-compliant

Operating voltage: 250 V (AC/DC)

Max. temperature: +40 °C

Min. temperature: -25 °C

Product type: Diode logic gate module

Documents & Downloads

Datasheet

Deutsch (Deutschland)

Datasheet 734397 WAGO 289-101 Diode gate module, rail mountable Content: 1 pc(s)

Description

Open diode gate with 8 1N4007 diodes, which can be wired individually.

This text is machine translated.
