Image similar
Image similar
Crouzet 88970021 Millenium 3 CB12 R PLC controller 24 V DC
EAN:
Part number:
Item no:
Datasheet (PDF)
4 Piece(s) (Only while stocks last)
Sales and shipping:
Number
Total (€ 159.66 / piece)
€
Only 4 Piece(s) available
Highlights & Details
Crouzet Millennium 3 controllers not expandable essential
- Simply a control system solution inside a modular casing
- Memory : 120 lines in LADDER language and up to 180 "typical" blocks in FBD language
- No display or parameter-setting buttons to avoid tampering by unauthorised users
- Analogue inputs 0-10 VDC or 0-20 mA/Pt 100 with converters
Technical specifications
IP40
IP20
- Type
Millenium 3 CB12 R
- Min. ambient temperature
-20 °C
- Max. ambient temperature
55 °C
- Manufacturer part #
88970021
- Dim
(L x W x H) 59.5 x 71.2 x 90 mm
- Height
90 mm
- Length
59.5 mm
- Width
71.2 mm
- Display
No
- No. of analogue inputs
4
- No. of digital inputs (max.)
8
- No. of inputs (max.)
8
- No. of outputs (max.)
4
- No. of relay outputs (max.)
4
- Operating voltage
24 V DC
- Digital outputs
4 relays (8 A)
- Digital inputs
8 (4 analogue)
- Operating voltage
24 V DC (max)
- Max. operating voltage
24 V DC
- Operating voltage
24 V DC
- Product type
PLC controller
Documents & Downloads
Datasheet
Datasheet 197166 Crouzet 88970021 Millenium 3 CB12 R PLC controller 24 V DC
User & Safety Instructions
User & Safety Instructions 197166 Crouzet 88970021 Millenium 3 CB12 R PLC controller 24 V DC
Description
The standard controls of the Millennium 3 - family have numerous components such as cam gears, angle-dependent cam control, pump and load management, memory devices, pressure and flow measurement, controller (multi-point, PID analog or PWM), square root, sine, cosine, weighted average etc. This Millenium 3 begins where many stops and builds a cost-effective foundation for numerous applications in engineering, water supply, greenhouses and water treatment are just a few examples. PWM or pulse width modulation is moving towards a cost-effective process for heating and cooling processes, engines to proceed or produce a voltage 0-10 V / DC through a converter (low-cost analog outputs). The analog inputs can be used to process 00-10 V / DC 0-24 VDC.
