Highlights & Details
LAN, Wi-Fi IP-Rotatable/tilting camera;2880 x 1620 p;Dahua TechnologyPicoo Dual D1, DH-P5D-5F-PV;DH-IPC-P5DP-5F-PV-0280B/0600B-EUROutdoors
- Two lenses 5 MP fixed lens + 5 MP swivel and tilt lens
- Swivel range 0° - 352°, tilt 0° - 90°
- 10 MP total resolution for pin-sharp images
- Manual and motorized angle adjustment for flexible monitoring
- Night vision - up to 30 meters
- Intelligent detection of persons and vehicles with tracking (Smart tracking)
- Automatic patrol can be set for the protection of important zones
- Two-way audio for real-time communication
- Wi-Fi 6 technology
- Active deterrent with flashlight and siren
- Easy installation and use via the Imou APP
- Micro SD card up to 256 GB (not included)
- Weather-proof according to IP66
Technical specifications
- Resolution 10 MP (2 x 5 MP / 2880 x 1620 lenses)
- Video compression: H.265
- Image sensor: 2 x 1/3” 5 mega pixel progressive CMOS
- Fixed lens 2.8 mm, F1.6
- FIELD OF VIEW 95° (H), 53° (V), 110° (D)
- Vision: Up to 30 m (2 x IR LEDs), up to 20 m (2 x white LEDs)
- Swivel and tilt: Fixed lens with manual angle adjustment: -10 - 15° tilt
- PT lens 6 mm, F1.6
- FIELD OF VIEW 49° (H), 26° (V), 57° (D)
- Swivel and tilt: PT lens swivel range: 0° - 352°, tilt: 0° - 90°
- Vision: Up to 50 m (2 x IR LEDs), up to 40 m (2 x white LEDs)
- Frame rate: Mainstream: 2880 × 1620 15 fps, Substream: 640 × 360 15 fps
- Video bit rate: H.265: 768 kbps–4096 kbps
- Image rotation 0°/180°
- Audio compression: G.711a
- Network connection 2.4 WLAN, RJ45 1 x 100 Mbps Ethernet port
- WLAN IEEE 802.11a/b/g/n/ac/ax 2.4–2.4835 GHz, 2.4 GHz, EIRP≤20 dBm
- Power supply 12 V DC
- Energy consumption: Base: 2.6 W; max.: 10.6 W (Pulling-Stream + IR + PT-Movement + Siren and Warning light)
- Operating temperature: -20 °C to +50 °C
- Camera type
Rotatable/tilting camera
- Sensor size
8.5 mm (1/3")
- Sensor type
CMOS
- Focal length
2,8 mm
6 mm
- App compatibility
Yes
- Transfer type
LAN
Wi-Fi
- Wi-Fi standard
IEEE802.11b
IEEE802.11g
IEEE802.11n
IEEE802.11ac
IEEE802.11ax
- IR range (max.)
50 m
- Used at
Outdoors
- Type
microSD card (up to 256 GB)
- Width
119.1 mm
- Height
210 mm
- Depth
159.4 mm
- Dim
(W x H x D) 119.1 x 210 x 159.4 mm
- Weight
585 g
- F-numbers
F1.6
- Factory colour
White
- Resolution (max.)
2880 x 1620 p
IP66
- Signal standard
IP
- CCTV features
2 lenses
2-way communication
Microphone
Speaker
IR LEDs
ONVIF support
Identity recognition
Vehicle recognition
Saves footage on SD card
Sounder
Show more
- Power supply
12 V / DC
Manufacturer-specific
- Product type
CCTV camera
Documents & Downloads
Datasheet
Datasheet 3436415 Dahua Technology Picoo Dual D1, DH-P5D-5F-PV DH-IPC-P5DP-5F-PV-0280B/0600B-EUR LAN, Wi-Fi IP CCTV camera 2880 x 1620 p
User & Safety Instructions
User & Safety Instructions 3436415 Dahua Technology Picoo Dual D1, DH-P5D-5F-PV DH-IPC-P5DP-5F-PV-0280B/0600B-EUR LAN, Wi-Fi IP CCTV camera 2880 x 1620 p
Description
The Dahua Pico Dual D1 wireless camera with two lenses (5 megapixels, 2880 x 1620 each) offers a high resolution that allows you to capture even the smallest details accurately. The swivel range from 0° to 352° and tilt range from 0° to 90° ensure flexible monitoring of all areas. The integrated intelligent LED lights enable night vision in color of up to 20 meters with the fixed lens and an IR night view of up to 30 meters, while the PT lens provides a visual range in color of up to 40 meters and up to 50 meters as an IR night view. This means that important details remain visible even in total darkness.
Other features include AI-assisted detection of people and vehicles with automatic tracking that ensure reliable monitoring. The Pico Dual D1 also provides you with the option to set up an automatic patrol, with which the camera automatically covers and monitors the most important points in your property. The camera is certified according to IP66, WAS makes it weather-proof and protects it against snow, rain and dust – Ideal for use in the outdoor area.
The control is done conveniently via the free Dahua APP for iOS and Android, so that you can access the live stream with just a few clicks, receive movement alerts and save important moments. With the 2-way audio function, direct communication is possible, for example to welcome guests or warn intruders. It offers integrated sound and light alarm functions.
The Bluetooth pairing function enables quick and easy installation, so that the camera can be used within a short time.
The connection to the network is made via the latest 2.4 GHz WiFi6-technology as well as an RJ-45 LAN-connection, WAS ensures a stable and fast data transfer. The use of the H.265 coding reduces data consumption while maintaining high image and sound quality. Built-in sound and light alarms can be activated manually or automatically to scare off unwanted guests.
The Dahua Pico Dual D1 supports several storage options: Micro SD card with up to 256 GB (not included), network recorder (NVR).
This text is machine translated.
Features
- Pico Dual D1 (DH-P5D-5F-PV)
- Day/Night: Auto (ICR)/Color/B/W.
- Audio: Two-way audio with built-in speaker and microphone
- Siren: Yes
- Motion detection: Yes
- Person recognition: Yes
- Vehicle recognition: Yes
- WLAN-coupling: Bluetooth-coupling
- Memory options: Supports Micro SD card (up to 256 GB)
- Operating software: DMSS
- Supported platforms: IOS, Android.
Scope of delivery
- Dahua Pico Dual D1 surveillance camera
- Waterproof covering
- Mains adapter
- Drill template
- Quick guide
- Mounting set
- Legal information
