MEAN WELL SD-25A-24 DC/DC converter 26 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
7 Piece(s)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 24.36
3
4% = € 1.06
€ 23.30
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 24.36 / piece)
€
Only 7 Piece(s) available
Technical specifications
- Type
SD-25A-24
- Min. input voltage
9.2 V DC
- Input voltage (max.)
18 V DC
- No. of outputs
1 x
26 W
- Connection
Screw terminal
- Dim
(L x W x H) 99.00 x 97.00 x 36.00 mm
- Height
36.00 mm
- Length
99.00 mm
- Width
97.00 mm
- Content
1 pc(s)
- Output voltage (max.)
24 V DC
- No. of inputs
1 x
- Output current (details)
1.1 A
- Type
Synchronised
- Weight
366.67 g
- Product type
DC/DC converter
Documents & Downloads
Datasheet
Datasheet 1292691 MEAN WELL SD-25A-24 DC/DC converter 26 W No. of outputs: 1 x Content 1 pc(s)
Information
Information 1292691 MEAN WELL SD-25A-24 DC/DC converter 26 W No. of outputs: 1 x Content 1 pc(s)
Conformity certificate
Conformity certificate 1292691 MEAN WELL SD-25A-24 DC/DC converter 26 W No. of outputs: 1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1292691 MEAN WELL SD-25A-24 DC/DC converter 26 W No. of outputs: 1 x Content 1 pc(s)
Description
Enclosed case, screw terminals · Overload protection, pulsing hiccup shutdown, auto recovery · Wide input voltage range 2:1 · DC decoupling of input and output · Input/output insulation 1500V · Regulated output voltage · Short-circuit proof
Features
- Closed design (case), screw terminals
- Overload protection by switching off, auto recovery
- Wide input voltage range 2:1
- Galvanic isolation of input and output
- Input/output insulation 1500 V
- Regulated output voltage
- Short-circuit proof
