Digitus DN-95128-1 PoE extender 1 GBit/s IEEE 802.3af (12.95 W), IEEE 802.3at (25.5 W), IEEE 802.3bt, IEEE802.3af (15.4
EAN:
Part number:
Item no:
3 Piece(s)
Sales and shipping:
Number
Total (€ 62.18 / piece)
€
Only 3 Piece(s) available
Highlights & Details
Digitus 4 port gigabit 4-PoE extender, 802.3at, 60 W
- Supports 2/4 ports with PoE+, PoE
- Transmits data and power via a network cable to your (PoE-) network devices
- No additional power supply needed
Technical specifications
- PoE inputs 1 x 10/100/1000Base-T RJ45
- PoE outputs 4 x 10/100/1000Base-T RJ45
- PoE input voltage 50 - 57 VDC, up to 90 W (max. Class 5 - 4 PPoE)
- PoE output voltage 44-57 VDC, up to 30 W per port, 85W max.
- PoE power budget: 45 W @ IEEE 802.3at at 4PPPoE input
- PoE power budget: 20 W @ IEEE 802.3at at PoE+ input
- PoE power budget: 10 W @ IEEE 802.3af on PoE input
- PoE input PIN assignment: 1/2 (-), 3/6 (+), 7/8 (-), 4/5 (+)
- PoE output PIN assignment: 1/2 (-), 3/6 (+)
- Meets the following standards: IEEE802.3af (PoE), IEEE802.3at (PoE+), IEEE802.3at (4PPoE)
- LED indicators: PoE active, link active
- Recommended network cables: CAT 5e or higher
- Max. Forward rate: 1,488 Mpps per port / 7.44 Mpps total
- Switch architecture: Store-and-forward
- Mac addresses: 2K
- Backplane Bandwidth: 10 Gbps
- Buffer 2 Mbit/s.
- IEEE 802.3x full duplex flow control
- Operating temperature: 0°C to 40°C
- Operating humidity: Max. 90% (non-condensing)
- Industrial use: No.
- PoE
IEEE 802.3af (12.95 W)
IEEE 802.3at (25.5 W)
IEEE 802.3bt
IEEE802.3af (15.4 W)
IEEE802.3at (30 W)
- LAN data transfer rate
1 GBit/s
- Weight
0.432
- Product type
PoE extender
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2895394 Digitus DN-95128-1 PoE extender 1 GBit/s IEEE 802.3af (12.95 W), IEEE 802.3at (25.5 W), IEEE 802.3bt, IEEE802.3af (15.4
Description
The Digitus® Gigabit 4PPoE Extender supports the latest network technology to extend your Ethernet signal up to 100 meters. The amplifier is supplied with power via 4PPPoE (4-Pair Power over Ethernet or lower), thus you do not need an additional power supply and can use the device even where there are no power lines or sockets in order to increase the range of the network considerably. PoE+ and 4PPPoE support also allows devices with higher power consumption to be connected, such as access points, POS systems or video phones. Rely on trend-setting 4PPoE technology with the gigabit 4PPoE extender from Digitus®.
This text is machine translated.
This text is machine translated.
Features
- Automatic detection of PoE network devices
- Easy Plug and Play installation
- Full bandwidth over the entire PoE distance
Scope of delivery
- Gigabit 4PPPoE Extender, 60 W, 4-port
- QIG
