Two red glass ampoules with the inscription 'SOD-80C', which are tightly sealed. They appear to contain medical or chemical contents.

Image similar

Two red glass ampoules with the inscription 'SOD-80C', which are tightly sealed. They appear to contain medical or chemical contents.

Image similar

Enclosure

SOD 80

Reverse voltage U(R)

50 V

Forward current I(F)

2 A

Forward voltage U(F)

0.95 V

Mounting type

Surface-mount

Datasheet (PDF)

English

Diotec

1699 Piece(s)

Sales and shipping:

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Minimum order quantity: 100

Total (€ 0.0601 / piece)

€

Report legal concerns

Technical specifications

Type SMDSOD 80 housingPeriodic Peak Reverse Voltage - VRRM 50 VContinuous current - IFAV 0.02 AJunction temperature - Tjmax 125 °CForward voltage - VF 0.95 VIF 0.02 ASurge current - IFSM 2.00 AReverse current - IR 0,200 µAVR 50 VLock layer capacity - CJ: PFVR V

Type: LL101B

Enclosure: SOD 80

Manufacturer: Diotec

Reverse voltage U(R): 50 V

Forward current I(F): 2 A

Reverse leakage current I(r): 0.200 µA

Peak forward surge current I(FSM): 2 A

Forward voltage U(F): 0.95 V

Operating temperature (max.): 125 °C

Mounting type: Surface-mount

RoHS-compliant: Yes

Content: 1 pc(s)

Product type: Schottky diode

Documents & Downloads

Datasheet

English

Datasheet 2809913 Diotec Schottky diode LL101B SOD 80 50 V
