Ehmann LUMEO MOBIL Pull dimmer Black Switching capacity (min.) 20 W Switching capacity (max.) 500 W 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
6 Piece(s)
Do your needs go beyond this?
Sales and shipping:
Number
Total (€ 35.59 / piece)
€
Only 6 Piece(s) available
Highlights & Details
NV-Halogen lamps leading edge cord dimmer
- Separate on/off switch
- Sliding controller for manual and foot operation
- With orientation light
- No standby consumption
Technical specifications
- Actuation: sliders and switches
- Control: phase angle control
- Suitable for: 230 V halogen lamps, NV-Halogen lamps with wound transformers
- Product type
Pull dimmer
- Factory colour
Black
- Length
130 mm
- Width
60 mm
- Height
35 mm
- Dim
(L x W x H) 130 x 60 x 35 mm
- Min. switching capacity
20 W
- Max. switching capacity
500 W
- Switching voltage
230 V AC
- Content
1 pc(s)
- Type
LUMEO MOBIL
Documents & Downloads
Datasheet
Datasheet 702399 Ehmann LUMEO MOBIL Pull dimmer Black Switching capacity (min.) 20 W Switching capacity (max.) 500 W 1 pc(s)
User & Safety Instructions
User & Safety Instructions 702399 Ehmann LUMEO MOBIL Pull dimmer Black Switching capacity (min.) 20 W Switching capacity (max.) 500 W 1 pc(s)
Description
Complete device for NV-Halogen lamps (with magnetic transformers), HV-Halogen lamps and bulbs The device has an in-built micro fuse, which can be changed, if necessary The required brightness can be adjusted via the sliding control; the device is switched on and off at the separate switch, without changing the background brightness. The orientation light on the device makes it easier to locate in the dark. With the various ways to connect the cord dimmer can be used alternatively as an intermediate or terminal.
