EWON EC6133C Cosy 131 WLAN Industrial router Wi-Fi, RJ-45 No. of inputs: 2 x No. of outputs: 2 x 12 V DC, 24 V DC 1 pc(s
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Total (€ 797.48 / piece)
€
Highlights & Details
EWON EC6133C Cosy 131 WLAN Industrial router Wi-Fi, RJ-45 No. of inputs: 2 x No. of outputs: 2 x 12 V DC, 24 V DC 1 pc(
- Remote maintenance saves travel time
- Firewall friendly
- Integrated WLAN and mobile phone connections
- Secure VPN connection
- 4 x Ethernet switch WAN/LAN configurable
Technical specifications
- Product type
Industrial router
- Interfaces
Wi-Fi
RJ-45
- Type
Cosy 131 WLAN
- Operating voltage
12 V DC
24 V DC
- Max. operating temperature
70 °C
- Min. operating temperature
-25 °C
- Operating temperature
-25 up to 70 °C
- No. of inputs
2 x
- No. of outputs
2 x
- Dim
- Manufacturer part #
EC6133C
Documents & Downloads
Datasheet
Datasheet 1616327 EWON EC6133C Cosy 131 WLAN Industrial router Wi-Fi, RJ-45 No. of inputs: 2 x No. of outputs: 2 x 12 V DC, 24 V DC 1 pc(s
User & Safety Instructions
User & Safety Instructions 1616327 EWON EC6133C Cosy 131 WLAN Industrial router Wi-Fi, RJ-45 No. of inputs: 2 x No. of outputs: 2 x 12 V DC, 24 V DC 1 pc(s
Information
Information 1616327 EWON EC6133C Cosy 131 WLAN Industrial router Wi-Fi, RJ-45 No. of inputs: 2 x No. of outputs: 2 x 12 V DC, 24 V DC 1 pc(s
Description
The eWON Cozy (COmmunication made eaSY) is an industrial VPN router specially designed for remote maintenance of customer equipment and machinery via the Internet. eWON Cozy allows OEMs, service engineers and SI companies to carry out maintenance operations remotely instead of calling on-site which significantly cuts product support costs.
Firewall-friendly
eWON cozy connects via your company's LAN (HTTPS port 443 or UDP 1194). No need to make any changes to IT or firewalls. Your IT support is gonna love it!
Built-in Wi-Fi and MTS
Built-in Wi-Fi and MTS modems enable internet connectivity without using the company LAN. Means no charges, lots of bandwith, easy availability (no wiring required) and safe network administration.
VPN tunneling
Information exchange is protected via SSL-based VPN tunneling. All data transfers are 2048-bit SSL-encrypted. Ensures that only authorised parties can connect to the eWON.
Plug'n Route
Plug'n Route means being able to connect to any Ethernet device without the need to change gateway settings or turn off equipment.
4 WAN/LAN Ethernet switch configurations
Connect up to 3 devices to the eWON and access them remotely via VPN. Means, in most cases, additional control unit switches are no longer necessary.
This text is machine translated.
Firewall-friendly
eWON cozy connects via your company's LAN (HTTPS port 443 or UDP 1194). No need to make any changes to IT or firewalls. Your IT support is gonna love it!
Built-in Wi-Fi and MTS
Built-in Wi-Fi and MTS modems enable internet connectivity without using the company LAN. Means no charges, lots of bandwith, easy availability (no wiring required) and safe network administration.
VPN tunneling
Information exchange is protected via SSL-based VPN tunneling. All data transfers are 2048-bit SSL-encrypted. Ensures that only authorised parties can connect to the eWON.
Plug'n Route
Plug'n Route means being able to connect to any Ethernet device without the need to change gateway settings or turn off equipment.
4 WAN/LAN Ethernet switch configurations
Connect up to 3 devices to the eWON and access them remotely via VPN. Means, in most cases, additional control unit switches are no longer necessary.
This text is machine translated.
