Finder 34.51.7.048.0019 PCB relay 48 V DC 6 A 1 change-over 1 pc(s)
EAN:
Part number:
Item no:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
20
-
€ 7.55
60
6% = € 0.46
€ 7.09
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 20
Multiple: 20
Total (€ 7.55 / piece)
€
Technical specifications
- With removable terminals: No.
- Drive, polarity: Non-polar
- Switching characteristics of drive: Mono-stable
- With positively driven contacts: No.
- Type of switch contact: Single contact
- Complete unit with socket: No.
- Type
34.51.7.048.0019
- Coil nominal voltage
48 V DC
- Contact type
1 change-over
- Switching current (max.)
6 A
IP20
- Width
15 mm
- Height
5 mm
- Depth
28 mm
- Dim
(W x H x D) 15 x 5 x 28 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Product type
PCB relay
Description
Narrow PCB relay, 1 changeover contact for 6 A/250 V AC, contact material AgNi, coil data 48 V DC, 0.170 W, 12300 Ohm, relay protection: RT II, horizontal with angled pins.
