Finder 83.91.0.240.0000 83.91.0.240.0000 TDR Multifunction 1 pc(s) Time range: 0.05 s (min) 1 change-over
EAN:
Part number:
Item no:
Product type
TDR
Type
Multifunction
Functions
Flasher, asymmetric, pulse OFF
Flasher through auxiliary contact, asymmetric, pulse ON
Flasher, asymmetric, pulse OFF
Flasher through auxiliary contact, asymmetric, pulse OFF
Min. operating voltage
24 V DC
24 V AC
Max. operating voltage
240 V DC
240 V AC
Datasheet (PDF)
59 Piece(s)
Sales and shipping:
Number
Total (€ 77.30 / piece)
€
Highlights & Details
Multi-functional industrial timer relay 83.91.0.240.0000
Technical specifications
- Product type
TDR
- Type
83.91.0.240.0000
- Type
Multifunction
- Connection
Screw terminal
- Functions
Flasher, asymmetric, pulse OFF
Flasher through auxiliary contact, asymmetric, pulse ON
Flasher, asymmetric, pulse OFF
Flasher through auxiliary contact, asymmetric, pulse OFF
- Min. operating voltage
24 V DC
24 V AC
- Max. operating voltage
240 V DC
240 V AC
- Operating voltage
24, 24 - 240, 240 V DC, V AC
- Contact type
1 change-over
- Contact material
AgNi
- Switching voltage (max.)
400 V AC
- Switching current (max.)
16 A
- Max. switching capacity
4000 VA
- Time range (min.)
0.05 s
- Time range(s)
1 s
10 s
1 min
10 min
1 h
10 h
1 d
10 d
- Min. temperature
-20 °C
- Max. temperature
+60 °C
IP20
- Electrical lifespan
50 x 10³ switching cycles
- Width
22.5 mm
- Height
78.8 mm
- Depth
100.3 mm
- Dim
(W x H x D) 22.5 x 78.8 x 100.3 mm
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 430008 Finder 83.91.0.240.0000 83.91.0.240.0000 TDR Multifunction 1 pc(s) Time range: 0.05 s (min) 1 change-over
User & Safety Instructions
User & Safety Instructions 430008 Finder 83.91.0.240.0000 83.91.0.240.0000 TDR Multifunction 1 pc(s) Time range: 0.05 s (min) 1 change-over
Information
Information 430008 Finder 83.91.0.240.0000 83.91.0.240.0000 TDR Multifunction 1 pc(s) Time range: 0.05 s (min) 1 change-over
Description
Industrial timer relay with multi-voltage input - self-day voltage adjustment by pulse width modulation.
This text is machine translated.
This text is machine translated.
Hints
Approvals: CULus, EAC, RINA, LR.
