GW Instek 01SR34HF30GT Bench PSU (adjustable voltage) 200 - 400 V 20 - 40 A 4000 W USB , LAN, RS232, GPIB
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number
Total (€ 11,326.89 / piece)
€
Highlights & Details
GW Instek 01SR34HF30GT Bench PSU (adjustable voltage) 200 - 400 V 20 - 40 A 4000 W USB , LAN, RS232, GPIB
- 200 - 400 V / 20 - 40 A
- 4000 W
- USB , LAN, RS232, GPIB
Technical specifications
- Max. Input current 30 A
- Type
01SR34HF30GT
- Product type
Bench PSU (adjustable voltage)
4000 W
- Interfaces
USB
LAN
RS232
GPIB
- Dim
(L x W x H) 550 x 430 x 176 mm
Manufacturer's standards (no certificate)
- Input voltage
264 V AC
- Weight
25 kg
- Output voltage (max.)
400 V
- Output voltage (min.)
200 V
- Max. output current
40 A
- Output current (min.)
20 A
- Width
430 mm
- Height
176 mm
- Length
550 mm
- Max. temperature
+40 °C
- Min. temperature
0 °C
Documents & Downloads
Datasheet
Datasheet 2813204 GW Instek 01SR34HF30GT Bench PSU (adjustable voltage) 200 - 400 V 20 - 40 A 4000 W USB , LAN, RS232, GPIB
User & Safety Instructions
User & Safety Instructions 2813204 GW Instek 01SR34HF30GT Bench PSU (adjustable voltage) 200 - 400 V 20 - 40 A 4000 W USB , LAN, RS232, GPIB
Description
The ASR-3000-series is Ideal for the development of on-board chargers, server-power supplies, LED-modules, AC-motors, AC-fans, UPS and various electronic components as well as for testing electrical devices for the automotive industry and household appliances.
