Hazet 6403-1 Forward/reverse ratchet socket bit
EAN:
Part number:
Item no:
20 Piece(s)
Sales and shipping:
Number
Total (€ 109.24 / piece)
€
Technical specifications
- Material
Chromium-vanadium steel
- Downforce
Square, solid, 12.5 mm (1/2")
- Dim
(L x W x H) 75 x 40 x 40 mm
- Weight
291 g
- Content
1 pc(s)
- Product type
Forward/reverse ratchet socket bit
- Width
40 mm
- Height
40 mm
- Length
75 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1288876 Hazet 6403-1 Forward/reverse ratchet socket bit
Description
• 6401-1 20 teeth ∙ Operating angle 18° – maximum 40 Nm - 6402-1 30 teeth ∙ Operating angle 12° – maximum 120 Nm - 6403-1 32 teeth ∙ Operating angle 11.25° – maximum 120 Nm - 6404-1 32 teeth ∙ Operating angle 11.25° – maximum 300 Nm . · Drop-forged. • Surface: Chrome-plated. • DIN 3120, ISO 1174-1. • Made In Germany. • Drive: Square socket insert 9 x 12 mm. • Drive: Square 12.5 mm (1/2 inches). • Dimensions / length 74.5 mm. • Net weight (kg): 0.29 kg. • Number of teeth: 32 (operating angle 11.25°). • Pitch of adjustment tool l2: 38.5 mm. • Head thickness a: 19.6 mm. • Head width b: 40 mm.
This text is machine translated.
This text is machine translated.
Features
- 6401-1 20 teeth - max 40 Nm - 6402-1 30 teeth - max 120 Nm - 6403-1 32 teeth - max 120 Nm - 6404-1 32 teeth - max 300 Nm
- Drop forged
- Surface: chrome-plated
- Square according to DIN 3120, ISO 1174-1
- Made in Germany
- Total length (for eClass): 745 mm
- Drive: Insert square 9 x 12 mm
- Output: Square, solid 125 mm (1/2 inch)
- Net weight: 029 kg
