Hazet 6606D-19 Box wrench socket bit 19 mm
EAN:
Part number:
Item no:
20 Piece(s)
Sales and shipping:
Number
Total (€ 100.83 / piece)
€
Technical specifications
- Dim
(L x W x H) 81 x 40 x 40 mm
- Weight
200 g
- Content
1 pc(s)
- Height
40 mm
- Length
81 mm
- Width
40 mm
- No. of teeth
40
- Downforce
Double hex socket profile
- Drive
Square socket bit 14 x 18 mm
- Material properties
chrome plated
- Size
19 mm
- Spanner size
19 mm
- Product type
Box wrench socket bit
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1288889 Hazet 6606D-19 Box wrench socket bit 19 mm
Description
• Switch function. • 40 teeth ∙ Operating angle 9°. • Max. 320 Nm · Drop-forged. • Deeper switching protects against unintentional switching. • Especially for Hazet torque wrench 6291-1CT – 6293-1CT. • Especially flat, recessed construction for work in confined spaces. • Surface: Chrome-plated. • Made In Germany. • Drive: Square socket insert 14 x 18 mm. • Output: Outer double-hexagon profile. • Width 19 mm. • Dimensions / length 81 mm. • Net weight (kg): 0.2 kg. • Number of teeth: 40 (operating angle 9°). • Pitch of adjustment tool l2: 36 mm. • Head thickness a: 14.3 mm. • Head thickness (a1): 20.5 mm. • Head width b: 40 mm.
This text is machine translated.
This text is machine translated.
Features
- With reversing switch
- 40 teeth
- Max 320 Nm
- Drop forged
- Deep-set reversing switch prevents unintentional change-over
- Especially suitable for HAZET Torque Wrenches° 6291-1CT - 6293-1CT
- Extra flat design with deep offset allows application in areas with restricted access
- Surface: chrome-plated
- Made in Germany
- Wrench size: 19
- Total length (for eClass): 81 mm
- Drive: Insert square 14 x 18 mm
- Output: Outside 12-point profile
- Net weight: 02 kg
