Keithley 2230-30-6 Bench PSU (adjustable voltage) 0 - 30 V DC 0 - 6 A 375 W No. of outputs 3 x
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Number
Total (€ 2,528.57 / piece)
€
Highlights & Details
Keithley 2230-30-6 Bench PSU (adjustable voltage) 0 - 30 V DC 0 - 6 A 375 W No. of outputs 3 x
- No. of outputs 3 x
- 0 - 30 V DC / 0 - 6 A
- 0 - 30 V DC /
- 5 V DC (max.) /
- 375 W
Technical specifications
- Type
2230-30-6
- Product type
Bench PSU (adjustable voltage)
- No. of outputs
3 x
375 W
- Technology
Linear regulated PSU
- Dim
Manufacturer's standards (no certificate)
- Output voltage (max.)
30 V DC
- Output voltage (min.)
0 V DC
- Output voltage 2 (max.)
30 V DC
- Output voltage 2 (min.)
0 V DC
- Output voltage 3 (max.)
5 V DC
- Max. output current
6 A
- Output current (min.)
0 A
Documents & Downloads
Datasheet
Datasheet 2585632 Keithley 2230-30-6 Bench PSU (adjustable voltage) 0 - 30 V DC 0 - 6 A 375 W No. of outputs 3 x
User & Safety Instructions
User & Safety Instructions 2585632 Keithley 2230-30-6 Bench PSU (adjustable voltage) 0 - 30 V DC 0 - 6 A 375 W No. of outputs 3 x
Description
The 2230 series of programmable 3-channel power supplies provide up to 375W of power in a space-saving 2U high, half-rack wide housing for automotive circuits. The 2230-30-6 offers 375 W with two 30 V, 6 A channels and a 5 V, 3 A channel.
This text is machine translated.
This text is machine translated.
Features
- All channels have isolated outputsAll channels are controlled independantlyAll channels have remote measurementTwo 30 V channels can be combined either in series or in parallelLow-noise, linear controlVoltage and current outputs for all channels are displayed simultaneouslyNumerical keypad input on the front panelStores frequently used configurations in 30 setup memories
