KS Tools 6201301 Puller Clamping range (details) 15 - 80 mm No. of hooks 2
EAN:
Part number:
Item no:
Number
Total (€ 65.54 / piece)
€
Only 5 Piece(s) available
Technical specifications
- Pull hook width G: 22 mm
- Pull hook total depth F: 22 mm
- Pull hook height D 3 mm
- Pull hook tip depth E: 12 mm
- Number of pull hooks: With 2 pull-off hooks
- Hexagon drive in mm: 17 mm
- Torque max Nm:60 Nm
- Function attribute 1: Reversible, interior/exterior removal
- Weight 900 g
- Material1: Special tool steel
- max. Compressive strength KN: 35.0
- max. Compression force Nm: 60
- max. Pressure force t: 3.5
- Quick adjustment: No. nein
- Clamping depth B in mm 100 mm
- Span A in mm 15 -80 mm
- Wingspan exterior puller C: 70-130
- Span up to [mm]: 80 mm
- Span [mm]: 15 mm
- Spindle size mm: M14x1.5 x 130
- Variant items : 620.1301
- Clamping range
15 - 80 mm
- Dim
- Weight
900 g
- Content
1 pc(s)
- Span depth (max.)
100 mm
- Hooks
2
- Product type
Puller
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2695356 KS Tools 6201301 Puller Clamping range (details) 15 - 80 mm No. of hooks 2
Description
It can be used as inside or outside puller by changing the hookHydraulic spindle can be retrofitted for thread G1/2" / G3/4"Extremely robust spindle with inductively hardened threadSpecial tool steel
