Image similar
Image similar
Lumberg 3114 05 Mini Module Empty Housing For indirect plug-ins Pins: 5
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Minimum order quantity: 10
Total (€ 0.20 / piece)
€
Highlights & Details
Lumberg 3114 05 Mini Module Empty Housing For indirect plug-ins Pins: 5
- Pitch 2.5 mm
Technical specifications
- Nominal current - rounded value
- DIN standard
DIN VDE 0110
- Pins per row
5
- Factory colour
Black
- Case material
PBT
- Manufacturer part #
3114 05
- Content
1 pc(s)
- Contact material
CuZn
- Width
5 mm
- Height
15.9 mm
- Length
15 mm
- Max. temperature
+100 °C
- Min. temperature
-25 °C
- Type
3114 05
- Dim
(L x W x H) 15 x 5 x 15.9 mm
- Total no. of pins
5
- Compatible with (details)
Crimpcontacts 3111
- Contact surface
Tin plated
- Material (details)
PBT, V0 as per UL 94
- Type
For indirect plug-ins
- Number of pins
5
- Nominal voltage (details)
125 V AC
- Certification marks
IEC 60664
- Pins
5
- Connection
-
- Temperature range
-25 to +100 °C
- RoHS-compliant
- Product type
Enclosure only
Documents & Downloads
Datasheet
Datasheet 732743 Lumberg 3114 05 Mini Module Empty Housing For indirect plug-ins Pins: 5
Description
Minimodul- connector system for cable-card- and card-card-connections. Simple conversion from single conductors to flat band cables Suitable for particularly small and medium series. For Signal- and low current loads upto 5 A. usage in household appliances, heating technique or communications technique. This Empty housing works for accepting Crimp contacts.
