Image similar
Image similar
Main switch 3-pin 32 A 3 breakers, 3 makers 240 V AC Eaton 276268
EAN:
Part number:
Item no:
Product type
Main switch
Nominal voltage
240 V AC
Number of pins
3
Nominal current - rounded value
32 A
Contact type
3 breakers
3 makers
Datasheet (PDF)
Show alternatives
Sales and shipping:
Number
Total (€ 37.81 / piece)
€
Technical specifications
- Rated breaking capacity: 12.5 kA
- Operating ambient temperature: -5 °C to +40 °C
- Width in division units: 3
- Installation depth: 69.5 mm
- Short-circuit resistance (ICW): 2 kA
- with signal lamp: No
- Protection class (IP): IP40
- Power loss of the equipment, current-dependant [PVID]: 1.6 W
- Power loss per pole, current-dependant [PVID]: 1.3 W.
- Product type
Main switch
- Contact type
3 breakers
3 makers
- Nominal voltage
240 V AC
- Number of pins
3
- Nominal current
32 A
- Nominal current - rounded value
32 A
IP40
AC
Other
FALSE
69.5 mm
32 A
415 V
0 W
3
Other
1 kA
12.5 kA
3
Symbol "arrows"
Other
Other
240 V
IP40
3
3
0
FALSE
