Image similar
MEAN WELL HLG-185H-36 LED driver, LED transformer Constant voltage, Constant current 187 W 5.2 A 36 V DC PFC circuit, Su
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
LED-switching power supply
- Constant voltage, Constant current
- 36 V DC
- 5.2 A
Technical specifications
- Protection class: IP67
- Product type
LED driver
- Type
Constant voltage
Constant current
- Dim
(L x W x H) 228.00 x 68.00 x 38.80 mm
- Output voltage (max.)
36 V DC
- Max. output current
5.2 A
- Output current (max.) - rounded
5.2 A
- Operating voltage
115 V AC
230 V AC
- LED driver features
PFC circuit
Surge protection
IP67
- Connection
Open end cable
- Max. power
187 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
305 V AC
- Min. input voltage
90 V AC
- Weight
1233.33 g
- Power range
187 W (max)
- Type
Synchronised
- Width
68.00 mm
- Height
38.80 mm
- Length
228.00 mm
Variants(All information is without VAT, plus shipping costs)
Type
Connection
Operating voltage
Max. power
IP rating
LED driver features
Output current (max.) - rounded
Output voltage (max.)
MEAN WELL HLG-185H-36 LED driver, LED transformer Constant voltage, Constant current 187 W 5.2 A 36 V DC PFC circuit, Surge protection 1 pc(s)
This article
Constant voltage
Open end cable
115 V AC
187 W
IP67
PFC circuit
5.2 A
36 V DC
Minimum order quantity: 1
Multiple: 1
€ 55.45*
MEAN WELL HLG-150H-12 LED driver, LED transformer Constant voltage, Constant current 150 W 12.5 A 12 V DC PFC circuit, Surge protection 1 pc(s)
Constant voltage
Open end cable
115 V AC
150 W
IP67
PFC circuit
12.5 A
12 V DC
Minimum order quantity: 1
Multiple: 1
€ 52.09*
MEAN WELL HLG-150H-24 LED driver, LED transformer Constant voltage, Constant current 150 W 6.3 A 24 V DC PFC circuit, Surge protection 1 pc(s)
Constant voltage
Open end cable
115 V AC
150 W
IP67
PFC circuit
6.3 A
24 V DC
Minimum order quantity: 1
Multiple: 1
€ 52.09*
MEAN WELL HLG-150H-36 LED driver, LED transformer Constant voltage, Constant current 150 W 4.2 A 36 V DC PFC circuit, Surge protection 1 pc(s)
Constant voltage
Open end cable
115 V AC
150 W
IP67
PFC circuit
4.2 A
36 V DC
Minimum order quantity: 1
Multiple: 1
€ 52.09*
MEAN WELL HLG-185H-12 LED driver, LED transformer Constant voltage, Constant current 156 W 13 A 12 V DC PFC circuit, Surge protection 1 pc(s)
Constant voltage
Open end cable
115 V AC
156 W
IP67
PFC circuit
13 A
12 V DC
Minimum order quantity: 1
Multiple: 1
€ 55.45*
MEAN WELL HLG-185H-24 LED driver, LED transformer Constant voltage, Constant current 187 W 7.8 A 24 V DC PFC circuit, Surge protection 1 pc(s)
Constant voltage
Open end cable
115 V AC
187 W
IP67
PFC circuit
7.8 A
24 V DC
Minimum order quantity: 1
Multiple: 1
€ 55.45*
MEAN WELL HLG-240H-12 LED driver, LED transformer Constant voltage, Constant current 192 W 16 A 12 V DC PFC circuit, Surge protection 1 pc(s)
Constant voltage
Open end cable
115 V AC
192 W
IP67
PFC circuit
16 A
12 V DC
Minimum order quantity: 1
Multiple: 1
€ 68.90*
MEAN WELL HLG-240H-36 LED driver, LED transformer Constant voltage, Constant current 241 W 6.7 A 36 V DC PFC circuit, Surge protection 1 pc(s)
Constant voltage
Open end cable
115 V AC
241 W
IP67
PFC circuit
6.7 A
36 V DC
Minimum order quantity: 1
Multiple: 1
€ 68.90*
MEAN WELL HLG-320H-12 LED driver, LED transformer Constant voltage, Constant current 264 W 22 A 12 V DC PFC circuit, Surge protection 1 pc(s)
Constant voltage
Open end cable
115 V AC
264 W
IP67
PFC circuit
22 A
12 V DC
Minimum order quantity: 1
Multiple: 1
€ 92.43*
MEAN WELL HLG-320H-24 LED driver, LED transformer Constant voltage, Constant current 320 W 13.3 A 24 V DC PFC circuit, Surge protection 1 pc(s)
Constant voltage
Open end cable
115 V AC
320 W
IP67
PFC circuit
13.3 A
24 V DC
Minimum order quantity: 1
Multiple: 1
€ 92.43*
Documents & Downloads
Datasheet
Datasheet 1293641 MEAN WELL HLG-185H-36 LED driver, LED transformer Constant voltage, Constant current 187 W 5.2 A 36 V DC PFC circuit, Su
Information
Information 1293641 MEAN WELL HLG-185H-36 LED driver, LED transformer Constant voltage, Constant current 187 W 5.2 A 36 V DC PFC circuit, Su
Warranty Terms
Warranty Terms 1293641 MEAN WELL HLG-185H-36 LED driver, LED transformer Constant voltage, Constant current 187 W 5.2 A 36 V DC PFC circuit, Su
Description
Universal input · Aluminium enclosure · Overload protection, current limiting, auto recovery · Protections: short circuit/over load/over voltage · Built-in active PFC function · Suitable for LED lighting and moving sign applications · EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13
Features
- Universal input
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage
- Built-in PFC circuit
- For LED lighting applications
- EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
