MEAN WELL HLG-600H-36A LED driver, LED transformer Constant voltage, Constant current 601 W 16.7 A 36 V DC PFC circuit,
EAN:
Part number:
Item no:
Datasheet (PDF)
50 Piece(s)
Sales and shipping:
Number
Total (€ 197.47 / piece)
€
Highlights & Details
LED-switching power supply
- Constant voltage, Constant current
- 36 V DC
- 16.7 A
Technical specifications
- Protection class: IP65
- Product type
LED driver
- Type
Constant voltage
Constant current
- Dim
(L x W x H) 48.50 x 280.00 x 144.00 mm
- Output voltage (max.)
36 V DC
- Max. output current
16.7 A
- Output current (max.) - rounded
16.7 A
- Operating voltage
115 V AC
230 V AC
- LED driver features
PFC circuit
Surge protection
adjustable
IP65
- Connection
Open end cable
- Max. power
601 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
305 V AC
- Min. input voltage
90 V AC
- Weight
3900.00 g
- Power range
601 W (max)
- Type
Synchronised
- Width
280.00 mm
- Height
144.00 mm
- Length
48.50 mm
Documents & Downloads
Datasheet
Datasheet 1293567 MEAN WELL HLG-600H-36A LED driver, LED transformer Constant voltage, Constant current 601 W 16.7 A 36 V DC PFC circuit,
Information
Information 1293567 MEAN WELL HLG-600H-36A LED driver, LED transformer Constant voltage, Constant current 601 W 16.7 A 36 V DC PFC circuit,
Warranty Terms
Warranty Terms 1293567 MEAN WELL HLG-600H-36A LED driver, LED transformer Constant voltage, Constant current 601 W 16.7 A 36 V DC PFC circuit,
Description
LED-power supply in aluminium enclosure with an input voltage range of 90~305VAC. Mixed Mode output (voltage stable to maximum current with subsequent constant current) (C.V.+C.C.), protection class IP65
Features
- Jet water and dust-proof
- Ideal for street lighting and sophisticated lighting systems
- Worldwide use
- Heavy duty metal casing
- Built-in protection against overvoltage, overheating, overload and short circuit
- Passive cooling
- Approvals: F, GS, CE, UL.
- This text is machine translated.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
