MEAN WELL LED transformer 50 W 4.16 A not dimmable 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 22.68
3
4% = € 0.98
€ 21.70
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 22.68 / piece)
€
Highlights & Details
LED SNT external 50W 12V 4.16A Euro
- 4.16 A
Technical specifications
- Product type
LED transformer
- Dim
(L x W x H) 75.5 x 32 x 47.5 mm
- Test mark
MM-Zeichen; SELV
- Max. output current
4.16 A
- Output current (max.) - rounded
4.16 A
- Operating voltage
12 V
- Protection class
II
- LED driver features
not dimmable
- Connection
Low power socket 5.5/2.1 mm
- Max. power
50 W
- No. of outputs
1 x
- Input voltage (max.)
373 V DC
264 V AC
- Min. input voltage
255 V DC
180 V AC
- Weight
240 g
- Power range
50 W (max)
- Width
32 mm
- Height
47.5 mm
- Length
75.5 mm
- Max. temperature
+40 °C
- Min. temperature
-20 °C
Documents & Downloads
Datasheet
Datasheet 2900948 MEAN WELL LED transformer 50 W 4.16 A not dimmable 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2900948 MEAN WELL LED transformer 50 W 4.16 A not dimmable 1 pc(s)
Warranty Terms
Warranty Terms 2900948 MEAN WELL LED transformer 50 W 4.16 A not dimmable 1 pc(s)
Description
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
