Omron G6S-2 5 VDC PCB relay 5 V DC 2 A 2 change-overs 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 2.51
10
7% = € 0.18
€ 2.33
25
10% = € 0.26
€ 2.25
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 2.51 / piece)
€
Technical specifications
- Surge resistance: (coil/contact, open contacts) 2500 V
- Sealed (RT III)
- Type
G6S-2 5 VDC
- Coil nominal voltage
5 V DC
- Control mode
monostable, 1 coil
- Resistance (coil)
178 Ω
- Contact type
2 change-overs
- Contact material
Ag + Au
- Switching voltage (max.)
220 V DC
250 V AC
- Switching current (max.)
2 A
- Max. switching capacity
60 W
62.5 VA
- Connection
Solder pins
- Electrical lifespan
100000 cycles
- Durability
100 x 106 cycles
- Min. temperature
-40 °C
- Max. temperature
+85 °C
- Length
14.8 mm
- Width
7.3 mm
- Height
9.2 mm
- Dim
(L x W x H) 14.8 x 7.3 x 9.2 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
- Engineering Part No
G6S25DC
- Engineering Series No
G6S25DC
- Type
THT
- Insulation resistance
500 V/DC 1000 MΩ
- Nominal voltage (details)
5 V DC
- Switching capacity
125 V/AC/0,5 A/30 V/DC/2 A, 62.5 VA/60 W
- Switching voltage
250 V/AC/220 V DC
- Switching current
2 A
- Dielectric strength
(Coil/contact) 2000 V/AC/(contact pair) 1500 V/AC/(open contacts) 1000 V AC
- Type
G6S-2 5 VDC
- Ambient temperature
-40 - +85 °C
- Product type
PCB relay
Documents & Downloads
Datasheet
Datasheet 503840 Omron G6S-2 5 VDC PCB relay 5 V DC 2 A 2 change-overs 1 pc(s)
Description
Mono-stable, poled telecom-relay of the new generation. Fulfils the requirements of high insulation and surge resistance of the Bellcore-standard with 2.5 kV between the contacts. Usual applications along with telecommunications are industrial applications with measurement tasks. Very low power intake of 140 mW. Can be soldered with infrared!
Hints
Approvals: UL, CSA.
