Image similar
1/4
Image similar
Panasonic APF30205 PCB relay 5 V DC 6 A 1 change-over 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.03
5
7% = € 0.27
€ 3.76
10
9% = € 0.37
€ 3.66
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 4.03 / piece)
€
Technical specifications
- Type
APF30205
- Coil nominal voltage
5 V DC
- Control mode
monostable, 1 coil
- Resistance (coil)
147 Ω
- Contact type
1 change-over
- Contact material
AgNi
- Switching voltage (max.)
250 V AC
- Switching current (max.)
6 A
- Max. switching capacity
1500 VA
- Creepage distance (coil/clips)
8 mm
- Connection
Solder pins
- Min. temperature
-40 °C
- Max. temperature
+85 °C
- Length
28 mm
- Width
5 mm
- Height
15 mm
- Dim
(L x W x H) 28 x 5 x 15 mm
- Content
1 pc(s)
- RoHS-compliant
- Product type
PCB relay
Documents & Downloads
Datasheet
Datasheet 505391 Panasonic APF30205 PCB relay 5 V DC 6 A 1 change-over 1 pc(s)
User & Safety Instructions
User & Safety Instructions 505391 Panasonic APF30205 PCB relay 5 V DC 6 A 1 change-over 1 pc(s)
Description
Slim power relay for power applications. Air and leakage current difference greater than 8 mm. Low power consumption and high switching capacity range. Meets the requirements of EN 60335-1 (Glow wire test) and the insulation requirements of EN/IEC 61810-1.
Application: Applications Interface, factory automation, PLC control, industrial and automation technology, household applications.
This text is machine translated.
Application: Applications Interface, factory automation, PLC control, industrial and automation technology, household applications.
This text is machine translated.
Hints
Approvals: VDE, UL, C-UL.
