Image similar
Image similar
Phoenix Contact Pin housing PCB SMC Total number of pins 2 Contact spacing: 3.81 mm 1827279 250 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Sales and shipping:
Number (Package size 250 pc(s))
Total (€ 0.47 / piece)
€
Highlights & Details
Base strip SMC 1,5/ 2-G-3,81
- Content: 250 pc(s)
- No. of rows: 1
- Total number of pins: 2
Technical specifications
- Connector type
Plug, horizontal mount
- Connector system
wire-to-board
- Series
SMC
- CS
3.81 mm
- Pins per row
2
- Total number of pins
2
- Nominal current
8 A
- Nominal current - rounded value
8 A
- Content
250 pc(s)
- Dim
(L x W x H) 9.01 x 14.40 x 13.10 mm
- Factory colour
Green
- Height
13.10 mm
- Length
9.01 mm
- Width
14.40 mm
- Industrial packaging
Yes
- Connection
Print
- Connector orientation
At an angle (to the PCB)
- Manufacturer part #
1827279
- Type
SMC 1,5/ 2-G-3,81
- Nominal voltage
160 V
- No. of rows
1
- Contact material
Tin plated
- Product type
Pin housing PCB
Documents & Downloads
Datasheet
Datasheet 717199 Phoenix Contact Pin housing PCB SMC Total number of pins 2 Contact spacing: 3.81 mm 1827279 250 pc(s)
User & Safety Instructions
User & Safety Instructions 717199 Phoenix Contact Pin housing PCB SMC Total number of pins 2 Contact spacing: 3.81 mm 1827279 250 pc(s)
Description
Header, Nominal current: 8 A, Rated voltage (III/2): 160 V, Number of positions: 2, Pitch: 3.81 mm, Color: green, Contact surface: Tin, Assembly: Soldering
