Image similar
Image similar
PTR Hartmann 54191040051F Spring-loaded terminal 0.75 mm² Number of pins 4 Pebble grey 1 pc(s)
EAN:
Part number:
Item no:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
7
-
€ 0.40
21
8% = € 0.03
€ 0.37
35
13% = € 0.05
€ 0.35
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 7
Total (€ 0.40 / piece)
€
Highlights & Details
Spring-loaded terminal
Technical specifications
- Features
+ push-in spring bracket
- CS
2.50 mm
- No. of rows
1
- Pins per row
4
- Number of pins
4
- Series
AK4191
- Min. stripping length
9 mm
- Stripping length (max.)
9 mm
- Connection
Spring-loaded terminal
Print
- Nominal current
2 A
- Cross section (flexible) (min.)
0.14 mm²
- Nominal current - rounded value
2 A
- Cross section (inflexible) (min.)
0.14 mm²
- Cross section (flexible) (max.)
0.75 mm²
- Cross section (inflexible) (max.)
0.75 mm²
- AWG (min.)
26
- Connector orientation
At an angle (to the PCB)
- AWG max.
20
- Contact material
Bronze
- Factory colour
Pebble grey
- Wire protection
Yes
- Content
1 pc(s)
- Height
12.00 mm
- Length
11.50 mm
- Width
16.60 mm
- Manufacturer part #
54191040051F
- Type
AK4191/4KDVP-2.5
- Nominal voltage
300 V
- Product type
Spring-loaded terminal
