Siemens 3RK1308-0DD00-0CP0 3RK13080DD000CP0 Reversing starter Motor power at 400 V 4 kW 500 V Nominal current 9 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Number
Total (€ 508.40 / piece)
€
Technical specifications
- Version of the motor protection: electronically
- Operating frequency: 50/60 Hz
- Number of pins: 3
- Number of digital inputs: 5
- Surge voltage resistance: 6 kV
- Product type
Reversing starter
- Motor power at 400 V
4 kW
- Nominal voltage
500 V
- Manufacturer part #
3RK13080DD000CP0
- Nominal current
9 A
- Nominal current - rounded value
9 A
- Type
3RK1308-0DD00-0CP0
- Dim
(W x H x D) 30 x 142 x 150 mm
- Width
30 mm
- Height
142 mm
- Depth
150 mm
- Max. temperature
+60 °C
- Min. temperature
-25 °C
30
142 mm
150 mm
FALSE
9 A
7
FALSE
TRUE
IP20
TRUE
DC
3.59 kW
Class 1
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1735690 Siemens 3RK1308-0DD00-0CP0 3RK13080DD000CP0 Reversing starter Motor power at 400 V 4 kW 500 V Nominal current 9 A
User & Safety Instructions
User & Safety Instructions 1735690 Siemens 3RK1308-0DD00-0CP0 3RK13080DD000CP0 Reversing starter Motor power at 400 V 4 kW 500 V Nominal current 9 A
Description
SIMOTICS S-1FK2 CT Servo motor M0=0.64 Nm PN = 0.2 kW at nN=3000 rpm Frequency converter at max. 240 V mains with holding brake Degree of protection IP64 Cylindrical shaft D14x30 mm Absolute encoder 20-bit + 12-bit multi-turn (encoder AM20DQC) with OCC interface Connector size M12, rotatable
