Siemens 3VA1196-4ED22-0AA0 Circuit breaker 1 pc(s) Adjustment range (amperage): 16 - 16 A Switching voltage (max.): 415
EAN:
Part number:
Item no:
Product type
Circuit breaker
Amperage adjustment range (max.)
16 A
Connection
Screws
Type
3VA1196-4ED22-0AA0
Amperage adjustment range (min.)
16 A
Datasheet (PDF)
Technical specifications
- Design: System Protection
- Power loss: 3.55 W
- Weight: 0.6 kg
- Mechanical life: 20000
- Electrical life: 8000
- Isolation voltage: 500 V
- Mains frequency: 50/60 Hz.
- Product type
Circuit breaker
- Type
3VA1196-4ED22-0AA0
- Amperage adjustment range (min.)
16 A
- Amperage adjustment range (max.)
16 A
- Adjustment range (amperage)
16 - 16 A
- No. of pins
2-pin
- Switching voltage (max.)
415 V AC
- Mounting type
Fixed
- Min. temperature
-25 °C
- Max. temperature
+70 °C
- Breaking capacity rating
S
- OCR type
TM210
- Connection
Screws
IP40
- Depth
70 mm
- Width
50.8 mm
- Height
130 mm
- Dim
(W x H x D) 50.8 x 130 x 70 mm
- Content
1 pc(s)
- RoHS-compliant
Yes
0
0
16 A
2
0
7.06 W
IP40
Front side
FALSE
Screw connection
Rocker lever
36 kA
TRUE
FALSE
FALSE
Built-in device fixed built-in technique
TRUE
TRUE
Documents & Downloads
Datasheet
Datasheet 1739291 Siemens 3VA1196-4ED22-0AA0 Circuit breaker 1 pc(s) Adjustment range (amperage): 16 - 16 A Switching voltage (max.): 415
User & Safety Instructions
User & Safety Instructions 1739291 Siemens 3VA1196-4ED22-0AA0 Circuit breaker 1 pc(s) Adjustment range (amperage): 16 - 16 A Switching voltage (max.): 415
Description
circuit breaker 3VA2 IEC frame 160 breaking capacity class M Icu=55kA @ 415 V 3-pole, motor protection ETU350m, LSI, In=100A overload protection ir=40A ...100A short circuit protection Isd=3... 15 x Ir, iI=15 x In cable connection undervoltage release (UVR) 208-230 V AC 50/60 Hz 2 auxiliary switch HQ
