SpeaKa Professional 2 ports KVM changeover switch HDMI USB 1920 x 1080 Pixel, 3840 x 2160 Pixel
EAN:
Part number:
Item no:
79 Piece(s)
Do your needs go beyond this?
Sales and shipping:
Number
Total (€ 84.03 / piece)
€
Highlights & Details
SpeaKa Professional 2 × 1 HDMI KVM switch with USB
- You can control up to 2 TV or computer signals
- Offers two additional USB 2.0 ports
- Independent switching of KVM, USB peripherals and audio via front button
- Supports 4K 2160P
Technical specifications
- Product type
KVM changeover switch
- No. of switchable PCs
2
- Video via
HDMI
- Video resolution
1920 x 1080 Pixel
3840 x 2160 Pixel
- Controller
USB
- Audio headphones
Yes
- Audio microphone
Yes
- No. of USB 2.0 ports
3 x
- Stackable
No
- Rack mount option
No
- Power supply (LOV)
via PSU
- Factory colour
Black
- Weight
0.8 kg
- Length
32 mm
- Width
270 mm
- Height
111 mm
- Port
2 ports
- Dim
(L x W x H) 32 x 270 x 111 mm
- Plastic free packaging
Plastic-free packaging
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1082615 SpeaKa Professional 2 ports KVM changeover switch HDMI USB 1920 x 1080 Pixel, 3840 x 2160 Pixel
Information
Information 1082615 SpeaKa Professional 2 ports KVM changeover switch HDMI USB 1920 x 1080 Pixel, 3840 x 2160 Pixel
Conformity certificate
Conformity certificate 1082615 SpeaKa Professional 2 ports KVM changeover switch HDMI USB 1920 x 1080 Pixel, 3840 x 2160 Pixel
Description
With the 2x1 HDMI USB KVM switch, you can network two PCs and output the signals to a HDMI TV or monitor. It supports resolutions up to 3840x2160 pixels, a video bandwidth of up to 6 GB/s, Dolby True HD and DTS HD Master Audio. In addition, the KVM switch via a metal casing for better HF-shielding and allows the user to switch between devices via front button between the signals.
The 2x1 HDMI USB KVM switch is HDMI v2.0 and HDCP-compliant and compatible with a variety of Windows and Mac operating systems.
This text is machine translated.
The 2x1 HDMI USB KVM switch is HDMI v2.0 and HDCP-compliant and compatible with a variety of Windows and Mac operating systems.
This text is machine translated.
Features
- Metal housing for increased HF-shielding
- Supports Dolby True HD and DTS HD Master Audio
- HDMI and HDCP-compatible
- Video bandwidth of up to 6 GB/s
- Compatible with Windows, Mac, Linux computer, game consoles, Blu-ray DVD players and other CE devices
Scope of delivery
- 4 x 1 USB HDMI - KVM switch
- HDMI & USB 2.0 to HDMI and USB 2.0 cable
- Power supply unit (5V/2A)
- Quick guide.
Hints
Since the power saving mode of the operating systems does not check for connected or active devices, but only for power consumption, this computer-side power saving function of the USB connections must be deactivated, so that the keyboard/mouse reacts again, faster and reliably after switching via the KVM switch.
System requirements
- Windows XP
- Windows Vista™
- Windows® 7
- Windows® 8
- Windows® 10
- Mac OS X 10.8 or higher
- Linux Kernel 2.6.x or higher
