Spelsberg 22704001 Cable gland shockproof, with strain relief, with locknut M40 Plastic Black 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable gland
External thread
M40
Type
straight, untreated, glass fiber reinforced
Material
Plastic
Clamp Ø
16 mm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 9.24
3
6% = € 0.53
€ 8.71
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 9.24 / piece)
€ 11.76
-21 %
€
Only 4 Piece(s) available
Technical specifications
- Thread pitch 1.5 mm
- Type of seal: Sealing ring
- Hexagonal corner dimensions 50 mm
- Product type
Cable gland
- Features
shockproof
with strain relief
with locknut
- Factory colour
Black
- External thread
M40
- Type
straight, untreated, glass fiber reinforced
- Material
Plastic
- Clamp Ø
16 mm
- Terminal Ø (max.)
28 mm
- Thread length
11 mm
- Min. temperature
-25 °C
- Max. temperature
+100 °C
IP68
- Spanner size
46 mm
- Halogen-free
Yes
- Content
1 pc(s)
- Manufacturer part #
22704001
- Type
KVR M40-MGM/sw
Black
Straight
TRUE
TRUE
9005
Untreated
46 mm
11 mm
TRUE
FALSE
TRUE
Sealing ring
Polyamide (PA)
-25-100 °C
Metric
Plastic
1.5 mm
FALSE
FALSE
FALSE
TRUE
50 mm
FALSE
16-28 mm
IP68
None
Other
40
None
FALSE
FALSE
Variants(All information is without VAT, plus shipping costs)
Clamp Ø
Factory colour
Terminal Ø (max.)
External thread
Features
Spelsberg 22704001 Cable gland shockproof, with strain relief, with locknut M40 Plastic Black 1 pc(s)
This article
16 mm
Black
28 mm
M40
shockproof
Minimum order quantity: 1
Multiple: 1
€ 9.24*
Spelsberg 22702001 Cable gland shockproof, with strain relief, with locknut M20 Plastic Black 1 pc(s)
6 mm
Black
12 mm
M20
shockproof
Minimum order quantity: 1
Multiple: 1
€ 3.18*
Spelsberg 22702101 Cable gland shockproof, with strain relief, with locknut M20 Plastic Black 1 pc(s)
7 mm
Black
14 mm
M20
shockproof
Minimum order quantity: 1
Multiple: 1
€ 3.35*
Spelsberg 22702501 Cable gland shockproof, with strain relief, with locknut M25 Plastic Black 1 pc(s)
9 mm
Black
16 mm
M25
shockproof
Minimum order quantity: 1
Multiple: 1
€ 3.35*
Spelsberg 22703201 Cable gland shockproof, with strain relief, with locknut M32 Plastic Black 1 pc(s)
11 mm
Black
21 mm
M32
shockproof
Minimum order quantity: 1
Multiple: 1
€ 4.03*
Spelsberg 22705001 Cable gland shockproof, with strain relief, with locknut M50 Plastic Black 1 pc(s)
27 mm
Black
34.5 mm
M50
shockproof
Minimum order quantity: 1
Multiple: 1
€ 17.64*
Spelsberg 22741201 Cable gland shockproof, with strain relief, with locknut M12 Plastic Light grey 1 pc(s)
2 mm
Light grey
6.5 mm
M12
shockproof
Minimum order quantity: 1
Multiple: 1
€ 1.92*
Spelsberg 22741601 Cable gland shockproof, with strain relief, with locknut M16 Plastic Light grey 1 pc(s)
4 mm
Light grey
10 mm
M16
shockproof
Minimum order quantity: 1
Multiple: 1
€ 2.76*
Spelsberg 22742001 Cable gland shockproof, with strain relief, with locknut M20 Plastic Light grey 1 pc(s)
6 mm
Light grey
12 mm
M20
shockproof
Minimum order quantity: 1
Multiple: 1
€ 3.18*
Spelsberg 22742101 Cable gland shockproof, with strain relief, with locknut M20 Plastic Light grey 1 pc(s)
6 mm
Light grey
12 mm
M20
shockproof
Minimum order quantity: 1
Multiple: 1
€ 3.35*
Documents & Downloads
Datasheet
Datasheet 2379484 Spelsberg 22704001 Cable gland shockproof, with strain relief, with locknut M40 Plastic Black 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2379484 Spelsberg 22704001 Cable gland shockproof, with strain relief, with locknut M40 Plastic Black 1 pc(s)
Description
Cable gland IP68 with strain relief, polyamide, M_ x 1.5mm, black, with locknut
