STMicroelectronics TDA7294V Linear IC - Audio amplifier 1-channel (mono) Class AB Multiwatt 15
EAN:
Part number:
Item no:
Enclosure
Multiwatt 15
Amplifier type
Class AB
Mounting type
Through-hole
Product type
Linear IC - Audio amplifier
Type
TDA7294V
Datasheet (PDF)
56 Piece(s)
Sales and shipping:
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 10.92
3
6% = € 0.61
€ 10.31
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 10.92 / piece)
€
Technical specifications
- Type
TDA7294V
- Enclosure
Multiwatt 15
- Manufacturer
STMicroelectronics
- Manuf. code
STM
- Amplifier type
Class AB
- Supply voltage (min.)
-10 V
+10 V
- Supply voltage (max.)
+40 V
- Output rating (max.)
100 W
- Output rating (max.) reference
8 Ω
- Output type
1-channel (mono)
- Channels
1
- Functions
Depop
Muting
Short-circuit and thermal protection
Standby
- Operating temperature (min.)
0 °C
- Operating temperature (max.)
+70 °C
- Mounting type
Through-hole
- Type
NF amp 100 W
- Output rating
(±38 V operating-voltage at 8 Ω) voltage:100 W
- Temperature range
0 - 70 °C
- Casing
Multiwatt® 15
- Product type
Linear IC - Audio amplifier
Documents & Downloads
Datasheet
Datasheet 177814 STMicroelectronics TDA7294V Linear IC - Audio amplifier 1-channel (mono) Class AB Multiwatt 15
User & Safety Instructions
User & Safety Instructions 177814 STMicroelectronics TDA7294V Linear IC - Audio amplifier 1-channel (mono) Class AB Multiwatt 15
Description
The TDA 7294 allows power output up to 100 W or 70 W constant power (RMS) with few external components. This compact, reliable, high-quality amplifier which is still good value for money can be used in active loudspeaker systems or as an integrated amplifier for audio systems. The DMOS chip located in the 15-pin housing features low noise and minimal distortion as well as effective short circuit and temperature protection. The mute function also prevents the irritating crackling that is damaging to speakers when they are turned on or off.
