Buy Surge protection 3RT29261BB00 + varistor Black 1 pc(s) Siemens 3RT2926-1BB00

Black rectangular component with metallic contacts at the top and bottom. Potentially an electronic or mechanical part.

An open electrical cabinet with visible cables and components. In the background, a rain-soaked glass pane, with blurred machinery behind it.

Overview of Schütz sizes and accessory parts with descriptions and connections. Highlighted main component: Schütz, size S0.

Circuit diagram: A battery with two parallel conductors, connected to a resistor, symbolised by the sign 'U'.

Technical drawing of a rectangular component by Siemens, with dimensions: 30.2 mm high, 11.5 mm wide on the side, 18.6 mm wide at the front.

1/5

Image similar

Product type

Surge protection

Content

1 pc(s)

Features

+ varistor

Factory colour

Black

Mounting type

Push-fit

Datasheet (PDF)

20 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Total (€ 16.80 / piece)

€

Report legal concerns

Technical specifications

Voltage type AC/DC
Size of contactor: S0
Control supply voltage frequency 60 Hz

Product type: Surge protection

Content: 1 pc(s)

Features: + varistor

Factory colour: Black

Mounting type: Push-fit

Min. operating voltage: 24 V AC
24 V DC

Max. operating voltage: 48 V AC
70 V DC

Operating voltage: 24, 24 - 48, 70 V AC, V DC

Compatible with: Siemens

Compatible with series: Siemens Sirius series

Min. temperature: -25 °C

Max. temperature: +60 °C

Width: 30 mm

Height: 19 mm

Length: 12 mm

Dim: (L x W x H) 12 x 30 x 19 mm

RoHS-compliant: Yes

Type: 3RT2926-1BB00

Type: 3RT 2926-1 BB00

: Varistor (voltage-sensitive resistor)

: AC/DC

Documents & Downloads

Datasheet

Datasheet 1430978 Surge protection 3RT29261BB00 + varistor Black 1 pc(s) Siemens 3RT2926-1BB00

User & Safety Instructions

User & Safety Instructions 1430978 Surge protection 3RT29261BB00 + varistor Black 1 pc(s) Siemens 3RT2926-1BB00

Description

Surge suppressor, varistor, AC 24 ... 48 V, DC 24 ... 70 V, for motor contactors size S0 Thanks to the mounting axis already in the contactor, the surge suppressor can be inserted very easily and without any effect on the external dimensions.
Simple, efficient, always up-to-date - the SIRIUS modular system.
