TDK B32560-J3104-K 1 pc(s) MKT thin film capacitor Radial lead 100 nF 250 V AC 10 % 7.5 mm (L x W x H) 9 x 3.2 x 6.1 mm
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
15
-
€ 0.22
45
9% = € 0.02
€ 0.20
75
14% = € 0.03
€ 0.19
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 15
Total (€ 0.22 / piece)
€
Technical specifications
- IEC climate category 55/105/56
- Max. voltage edge steepness Usslt in V/µs (at voltage swing Uss = UN)
- Diameter d1 = 0.5 mm
- Ueff = 160 V/AC
- Type
Radial lead
- Capacity (elec.)
100 nF
- Nominal voltage
250 V AC
- Dielectric
Polyethylene terephthalate (polyester) without sheath
- Tolerance ±
10 %
- Connection
Solder pins
- Length
9 mm
- Width
3.2 mm
- Height
6.1 mm
- CS
7.5 mm
- Content
1 pc(s)
- Dim
(L x W x H) 9 x 3.2 x 6.1 mm
- Cable Ø range
- Type
B32560-J3104-K
- Nominal voltage (details)
250 V AC
- Reliability
(bei 40 °C, 0.5 UN) 2 x 10-9/h = 2fit
- RoHS-compliant
Yes
- Dielectric
Polyethylenterephthalat (Polyester) ohne Umhüllung
- Product type
MKT thin film capacitor
Documents & Downloads
Datasheet
Datasheet 500784 TDK B32560-J3104-K 1 pc(s) MKT thin film capacitor Radial lead 100 nF 250 V AC 10 % 7.5 mm (L x W x H) 9 x 3.2 x 6.1 mm
Description
Extremely small layer capacitor, self healing.
Features
- Design standard: CECC 30401-007
Hints
1) Note clearances and distances! Dielectric strength of the cut surfaces 1.5
UN or at least 300 V / DC
2) For a voltage swing USSN can multiply the value of the permissible slope USS/t with a factor UN/USS.
³) B 32 560 (7.5 mm grid) for single sided bonded PCBs only.
