TE Connectivity 5103310-6 Pin strip Contact spacing: 2.54 mm Total number of pins: 26 No. of rows: 2 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.61
5
7% = € 0.30
€ 4.31
10
9% = € 0.42
€ 4.19
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.61 / piece)
€
Highlights & Details
AMP-latch pin trough
- Total number of pins 26
- No. of rows 2
- Content 1 pc(s)
Technical specifications
- Connector type
Pin strip, right angle
- CS
2.54 mm
- No. of rows
2
- Pins per row
13
- Total number of pins
26
- Nominal voltage
250 V AC
- Nominal current
1 A
- Contact material
Copper alloy
- Content
1 pc(s)
- Connection
Print
- Type
5103310-6
- Dim
(L x W x H) 40.64 x 3.81 x 8.81 mm
- Factory colour
Black
- Height
8.81 mm
- Length
40.64 mm
- Width
3.81 mm
- Connector contact surface
Gold plated
- Board contact surface
Tin plated
- Connector orientation
Parallel (to the PCB)
- Manufacturer part #
5103310-6
- Connector coating thickness
2.54 µm
- Case material
Polybutylene
- RoHS-compliant
Yes
- Max. temperature
+105 °C
- Min. temperature
-65 °C
- Product type
Pin strip
